KF59減速機銘牌參數說明解讀含義:有關型號描述的詳細情況及其他信息可以參閱本業附件下載中的K59減速機選型樣本。
KF59-YVB-0.75KW-4P-48.89-M6-270°
KF:系列代號
59:減速機規格代號
YVB:電機
0.75KW:電機功率
4P:電機級數
48.89:減速機傳動比
M6:減速機安裝位置
270°:接線盒位置
KF59減速機潤滑油型號:
KF59減速機某些安裝位置發生攪油損失的機會較高。出現下列情況時請與BOSERL公司進行聯系:若無特殊規定,BOSERL公司發貨時會根據KF59減速機的安裝位置給驅動裝置加潤滑油,因此應在訂貨時指定安裝位置(M1…M6,參見“KF59減速機說明書中的安裝位置與訂貨說明”章節)。若之后對安裝位置需要改動,則加潤滑油必須與安裝位置相符(潤滑油加注量)。直角減速機
KF59減速機潤滑油加注量,具體值根據級數與傳動比的不同而各異。請您在加注潤滑油時一定注意油位螺栓所指示的精確油量。本頁附件中的KF59減速機選型樣本中列出了安裝位置從M1到M6KF59減速機相應的潤滑油加注標準,請自行下載查看。
KF59減速機特殊應用場合必須使用特殊潤滑油,比如要求長使用壽命潤滑油。若需要可提供用于食品行業和生物降解潤滑油。齒輪減速電機
KF59減速機推薦使用的潤滑油,其等級和粘度指標見下表:
ISO標準潤滑油 | 粘貼指標 | 環境溫度°C | 減速機型號 |
MINERALOILCLP(cc) | ISOVG220 | -10-+40 | R系列、F系列、K系列減速機 |
ISOVG680 | 0-+40 | S系列減速機 |
ISO標準潤滑油 | 粘貼指標 | 環境溫度°C | 減速機型號 |
MINERALOILCLP(cc) | ISOVG100 | -20-+25 | R系列、F系列、K系列減速機 |
Synthetic fluid,clp pg | ISOVG220 | -25-+80 | R系列、F系列、K系列減速機 |
Synthetic fluid,CLP HC | ISOVG460 | -30-+80 | S系列減速機 |
KF59減速機使用說明:
KF59減速機警告說明:由于KF59減速機發熱或KF59減速機油溫過高可能引起燙傷;對KF59減速機進行操作前先冷卻;擰出油位檢查螺栓和放油螺栓時要格外小心。
KF59減速機注意事項:若未注入正確的KF59減速機油則可能造成潤滑油性能失效,可能造成財產損失;合成潤滑油不可能相互混用并不可與礦物潤滑油混用;礦物油用作標準的潤滑油,不能用于特殊行業。
KF59減速機提示事項:油位檢查螺栓、放油螺栓、以及透氣閥的位置在安裝位置上,要參見KF59減速機說明書安裝位置章節中的內容。
KF59減速機的螺母:立式安裝KF59減速機輸出法蘭螺母規格M12;KF59減速機螺母/螺母擰緊扭矩強度等級10.9。伺服電機減速機
KF59減速機危險使用說明:驅動裝置意外啟動會造成擠傷,可能造成重傷或死亡;開始工作前,應先斷開減速電機的電源并且采取措施防止意外接通!
KF59減速機型號:
WKF57-Y0.12SKF,WKF57-Y0.18SKF,WKF57-Y0.25SKF,WKF57-Y0.37SKF,WKF57-Y0.55SKF,WKF57-Y0.75SKF,WKF57-Y1.1SKF,WKF57-Y1.5SKF,WKF57-Y100M4,WKF57-Y112M4,WKF57-Y2.2SKF,WKF57-Y3SKF,WKF57-Y4SKF,WKF57-Y63M4,WKF57-Y71M4,WKF57-Y80M4,WKF57-Y90M4,WKF57-YB100M4,WKF57-YB112M4,WKF57-YB63M4,WKF57-YB71M4,WKF57-YB80M4,WKF57-YB90M4,WKF57-YDP100M4,WKF57-YDP112M4,WKF57-YDP63M4,WKF57-YDP71M4,WKF57-YDP80M4,WKF57-YDP90M4,WKF57-YE100M4,WKF57-YE112M4,WKF57-YE63M4,WKF57-YE71M4,WKF57-YE80M4,WKF57-YE90M4,WKF57-YEJ100M4,WKF57-YEJ112M4,WKF57-YEJ63M4,WKF57-YEJ71M4,WKF57-YEJ80M4,WKF57-YEJ90M4,WKF57-YEJB100M4,WKF57-YEJB112M4,WKF57-YEJB63M4,WKF57-YEJB71M4,WKF57-YEJB80M4,WKF57-YEJB90M4,WKF57-YP100M4,WKF57-YP112M4,WKF57-YP63M4,WKF57-YP71M4,WKF57-YP80M4,WKF57-YP90M4,WKF57-YPB100M4,WKF57-YPB112M4,WKF57-YPB63M4,WKF57-YPB71M4,WKF57-YPB80M4,WKF57-YPB90M4,WKF57-YPE100M4,WKF57-YPE112M4,WKF57-YPE63M4,WKF57-YPE71M4,WKF57-YPE80M4,WKF57-YPE90M4,WKF57-YS100M4,WKF57-YS112M4,WKF57-YS63M4,WKF57-YS71M4,WKF57-YS80M4,WKF57-YS90M4,WKF57-YVB100M4,WKF57-YVB112M4,WKF57-YVB63M4,WKF57-YVB71M4,WKF57-YVB80M4,WKF57-YVB90M4,WKF57-YVP100M4,WKF57-YVP112M4,WKF57-YVP63M4,WKF57-YVP71M4,WKF57-YVP80M4,WKF57-YVP90M4,WKF57-YVPEJ100M4,WKF57-YVPEJ112M4,WKF57-YVPEJ63M4,WKF57-YVPEJ71M4,WKF57-YVPEJ80M4,WKF57-YVPEJ90M4,SKF57-Y0.12SKF,SKF57-Y0.18SKF,SKF57-Y0.25SKF,SKF57-Y0.37SKF,SKF57-Y0.55SKF,SKF57-Y0.75SKF,SKF57-Y1.1SKF,SKF57-Y1.5SKF,SKF57-Y100M4,SKF57-Y112M4,SKF57-Y2.2SKF,SKF57-Y3SKF,SKF57-Y4SKF,SKF57-Y63M4,SKF57-Y71M4,SKF57-Y80M4,SKF57-Y90M4,SKF57-YB100M4,SKF57-YB112M4,SKF57-YB63M4,SKF57-YB71M4,SKF57-YB80M4,SKF57-YB90M4,SKF57-YDP100M4,SKF57-YDP112M4,SKF57-YDP63M4,SKF57-YDP71M4,SKF57-YDP80M4,SKF57-YDP90M4,SKF57-YE100M4,SKF57-YE112M4,SKF57-YE63M4,SKF57-YE71M4,SKF57-YE80M4,SKF57-YE90M4,SKF57-YEJ100M4,SKF57-YEJ112M4,SKF57-YEJ63M4,SKF57-YEJ71M4,SKF57-YEJ80M4,SKF57-YEJ90M4,SKF57-YEJB100M4,SKF57-YEJB112M4,SKF57-YEJB63M4,SKF57-YEJB71M4,SKF57-YEJB80M4,SKF57-YEJB90M4,SKF57-YP100M4,SKF57-YP112M4,SKF57-YP63M4,SKF57-YP71M4,SKF57-YP80M4,SKF57-YP90M4,SKF57-YPB100M4,SKF57-YPB112M4,SKF57-YPB63M4,SKF57-YPB71M4,SKF57-YPB80M4,SKF57-YPB90M4,SKF57-YPE100M4,SKF57-YPE112M4,SKF57-YPE63M4,SKF57-YPE71M4,SKF57-YPE80M4,SKF57-YPE90M4,SKF57-YS100M4,SKF57-YS112M4,SKF57-YS63M4,SKF57-YS71M4,SKF57-YS80M4,SKF57-YS90M4,SKF57-YVB100M4,SKF57-YVB112M4,SKF57-YVB63M4,SKF57-YVB71M4,SKF57-YVB80M4,SKF57-YVB90M4,SKF57-YVP100M4,SKF57-YVP112M4,SKF57-YVP63M4,SKF57-YVP71M4,SKF57-YVP80M4,SKF57-YVP90M4,SKF57-YVPEJ100M4,SKF57-YVPEJ112M4,SKF57-YVPEJ63M4,SKF57-YVPEJ71M4,SKF57-YVPEJ80M4,SKF57-YVPEJ90M4,AKF57-Y0.12SKF,AKF57-Y0.18SKF,AKF57-Y0.25SKF,AKF57-Y0.37SKF,AKF57-Y0.55SKF,AKF57-Y0.75SKF,AKF57-Y1.1SKF,AKF57-Y1.5SKF,AKF57-Y100M4,AKF57-Y112M4,AKF57-Y2.2SKF,AKF57-Y3SKF,AKF57-Y4SKF,AKF57-Y63M4,AKF57-Y71M4,AKF57-Y80M4,AKF57-Y90M4,AKF57-YB100M4,AKF57-YB112M4,AKF57-YB63M4,AKF57-YB71M4,AKF57-YB80M4,AKF57-YB90M4,AKF57-YDP100M4,AKF57-YDP112M4,AKF57-YDP63M4,AKF57-YDP71M4,AKF57-YDP80M4,AKF57-YDP90M4,AKF57-YE100M4,AKF57-YE112M4,AKF57-YE63M4,AKF57-YE71M4,AKF57-YE80M4,AKF57-YE90M4,AKF57-YEJ100M4,AKF57-YEJ112M4,AKF57-YEJ63M4,AKF57-YEJ71M4,AKF57-YEJ80M4,AKF57-YEJ90M4,AKF57-YEJB100M4,AKF57-YEJB112M4,AKF57-YEJB63M4,AKF57-YEJB71M4,AKF57-YEJB80M4,AKF57-YEJB90M4,AKF57-YP100M4,AKF57-YP112M4,AKF57-YP63M4,AKF57-YP71M4,AKF57-YP80M4,AKF57-YP90M4,AKF57-YPB100M4,AKF57-YPB112M4,AKF57-YPB63M4,AKF57-YPB71M4,AKF57-YPB80M4,AKF57-YPB90M4,AKF57-YPE100M4,AKF57-YPE112M4,AKF57-YPE63M4,AKF57-YPE71M4,AKF57-YPE80M4,AKF57-YPE90M4,AKF57-YS100M4,AKF57-YS112M4,AKF57-YS63M4,AKF57-YS71M4,AKF57-YS80M4,AKF57-YS90M4,AKF57-YVB100M4,AKF57-YVB112M4,AKF57-YVB63M4,AKF57-YVB71M4,AKF57-YVB80M4,AKF57-YVB90M4,AKF57-YVP100M4,AKF57-YVP112M4,AKF57-YVP63M4,AKF57-YVP71M4,AKF57-YVP80M4,AKF57-YVP90M4,AKF57-YVPEJ100M4,AKF57-YVPEJ112M4,AKF57-YVPEJ63M4,AKF57-YVPEJ71M4,AKF57-YVPEJ80M4,AKF57-YVPEJ90M4,NKF57-Y0.12SKF,NKF57-Y0.18SKF,NKF57-Y0.25SKF,NKF57-Y0.37SKF,NKF57-Y0.55SKF,NKF57-Y0.75SKF,NKF57-Y1.1SKF,NKF57-Y1.5SKF,NKF57-Y100M4,NKF57-Y112M4,NKF57-Y2.2SKF,NKF57-Y3SKF,NKF57-Y4SKF,NKF57-Y63M4,NKF57-Y71M4,NKF57-Y80M4,NKF57-Y90M4,NKF57-YB100M4,NKF57-YB112M4,NKF57-YB63M4,NKF57-YB71M4,NKF57-YB80M4,NKF57-YB90M4,NKF57-YDP100M4,NKF57-YDP112M4,NKF57-YDP63M4,NKF57-YDP71M4,NKF57-YDP80M4,NKF57-YDP90M4,NKF57-YE100M4,NKF57-YE112M4,NKF57-YE63M4,NKF57-YE71M4,NKF57-YE80M4,NKF57-YE90M4,NKF57-YEJ100M4,NKF57-YEJ112M4,NKF57-YEJ63M4,NKF57-YEJ71M4,NKF57-YEJ80M4,NKF57-YEJ90M4,NKF57-YEJB100M4,NKF57-YEJB112M4,NKF57-YEJB63M4,NKF57-YEJB71M4,NKF57-YEJB80M4,NKF57-YEJB90M4,NKF57-YP100M4,NKF57-YP112M4,NKF57-YP63M4,NKF57-YP71M4,NKF57-YP80M4,NKF57-YP90M4,NKF57-YPB100M4,NKF57-YPB112M4,NKF57-YPB63M4,NKF57-YPB71M4,NKF57-YPB80M4,NKF57-YPB90M4,NKF57-YPE100M4,NKF57-YPE112M4,NKF57-YPE63M4,NKF57-YPE71M4,NKF57-YPE80M4,NKF57-YPE90M4,NKF57-YS100M4,NKF57-YS112M4,NKF57-YS63M4,NKF57-YS71M4,NKF57-YS80M4,NKF57-YS90M4,NKF57-YVB100M4,NKF57-YVB112M4,NKF57-YVB63M4,NKF57-YVB71M4,NKF57-YVB80M4,NKF57-YVB90M4,NKF57-YVP100M4,NKF57-YVP112M4,NKF57-YVP63M4,NKF57-YVP71M4,NKF57-YVP80M4,NKF57-YVP90M4,NKF57-YVPEJ100M4,NKF57-YVPEJ112M4,NKF57-YVPEJ63M4,NKF57-YVPEJ71M4,NKF57-YVPEJ80M4,NKF57-YVPEJ90M4,GKF59-Y0.12SKF,GKF59-Y0.18SKF,GKF59-Y0.25SKF,GKF59-Y0.37SKF,GKF59-Y0.55SKF,GKF59-Y0.75SKF,GKF59-Y1.1SKF,GKF59-Y1.5SKF,GKF59-Y100M4,GKF59-Y112M4,GKF59-Y2.2SKF,GKF59-Y3SKF,GKF59-Y4SKF,GKF59-Y63M4,GKF59-Y71M4,GKF59-Y80M4,GKF59-Y90M4,GKF59-YB100M4,GKF59-YB112M4,GKF59-YB63M4,GKF59-YB71M4,GKF59-YB80M4,GKF59-YB90M4,GKF59-YDP100M4,GKF59-YDP112M4,GKF59-YDP63M4,GKF59-YDP71M4,GKF59-YDP80M4,GKF59-YDP90M4,GKF59-YE100M4,GKF59-YE112M4,GKF59-YE63M4,GKF59-YE71M4,GKF59-YE80M4,GKF59-YE90M4,GKF59-YEJ100M4,GKF59-YEJ112M4,GKF59-YEJ63M4,GKF59-YEJ71M4,GKF59-YEJ80M4,GKF59-YEJ90M4,GKF59-YEJB100M4,GKF59-YEJB112M4,GKF59-YEJB63M4,GKF59-YEJB71M4,GKF59-YEJB80M4,GKF59-YEJB90M4,GKF59-YP100M4,GKF59-YP112M4,GKF59-YP63M4,GKF59-YP71M4,GKF59-YP80M4,GKF59-YP90M4,GKF59-YPB100M4,GKF59-YPB112M4,GKF59-YPB63M4,GKF59-YPB71M4,GKF59-YPB80M4,GKF59-YPB90M4,GKF59-YPE100M4,GKF59-YPE112M4,GKF59-YPE63M4,GKF59-YPE71M4,GKF59-YPE80M4,GKF59-YPE90M4,GKF59-YS100M4,GKF59-YS112M4,GKF59-YS63M4,GKF59-YS71M4,GKF59-YS80M4,GKF59-YS90M4,GKF59-YVB100M4,GKF59-YVB112M4,GKF59-YVB63M4,GKF59-YVB71M4,GKF59-YVB80M4,GKF59-YVB90M4,GKF59-YVP100M4,GKF59-YVP112M4,GKF59-YVP63M4,GKF59-YVP71M4,GKF59-YVP80M4,GKF59-YVP90M4,GKF59-YVPEJ100M4,GKF59-YVPEJ112M4,GKF59-YVPEJ63M4,GKF59-YVPEJ71M4,GKF59-YVPEJ80M4,GKF59-YVPEJ90M4。
KF59減速機生產廠家展示:看廠請聯系微信13827261050,獲取位置,需提前一天預約http://njxyx.com/product/list-kfxiliejiansuji-cn.html
推薦類似型號:K59減速機
關鍵詞:帶伺服減速機_伺服電機減速機_伺服電機減速器_伺服減速器_大扭力減速機_大扭力減速器_交流減速機_GKF系列減速機_KF系列減速機_伺服電機減速機一體機_伺服減速機一體機_KF系列減速器
KF系列齒輪減速電機型號:KF39減速機,KF49減速機,KF59減速機,KF69減速機,KF79減速機,KF89減速機,KF99減速機,KF109減速機,KF129減速機,KF159減速機,KF167減速機,KF187減速機
KF系列直角減速機可配變頻電機,剎車電機,防爆電機,伺服電機,交流電機,直流電機,三相電機,單相電機 0.12KW-200KW之間
如需工程師幫選型,請加微信13827261050,留言告知工程師參數要求
