KF129減速機銘牌參數說明解讀含義:有關型號描述的詳細情況及其他信息可以參閱本業附件下載中的K129減速機選型樣本。
KF129-YVB-18.5KW-4P-110.18-M2-90°
KF:系列代號
129:減速機規格代號
YVB:電機
18.5KW:電機功率
4P:電機級數
110.18:減速機傳動比
M2:減速機安裝位置
90°:接線盒位置
KF129減速機潤滑油型號:
KF129減速機某些安裝位置發生攪油損失的機會較高。出現下列情況時請與BOSERL公司進行聯系:若無特殊規定,BOSERL公司發貨時會根據KF129減速機的安裝位置給驅動裝置加潤滑油,因此應在訂貨時指定安裝位置(M1…M6,參見“KF129減速機說明書中的安裝位置與訂貨說明”章節)。若之后對安裝位置需要改動,則加潤滑油必須與安裝位置相符(潤滑油加注量)。直角減速機
KF129減速機潤滑油加注量,具體值根據級數與傳動比的不同而各異。請您在加注潤滑油時一定注意油位螺栓所指示的精確油量。本頁附件中的KF129減速機選型樣本中列出了安裝位置從M1到M6KF129減速機相應的潤滑油加注標準,請自行下載查看。
KF129減速機特殊應用場合必須使用特殊潤滑油,比如要求長使用壽命潤滑油。若需要可提供用于食品行業和生物降解潤滑油。齒輪減速電機
KF129減速機推薦使用的潤滑油,其等級和粘度指標見下表:
ISO標準潤滑油 | 粘貼指標 | 環境溫度°C | 減速機型號 |
MINERALOILCLP(cc) | ISOVG220 | -10-+40 | R系列、F系列、K系列減速機 |
ISOVG680 | 0-+40 | S系列減速機 |
ISO標準潤滑油 | 粘貼指標 | 環境溫度°C | 減速機型號 |
MINERALOILCLP(cc) | ISOVG100 | -20-+25 | R系列、F系列、K系列減速機 |
Synthetic fluid,clp pg | ISOVG220 | -25-+80 | R系列、F系列、K系列減速機 |
Synthetic fluid,CLP HC | ISOVG460 | -30-+80 | S系列減速機 |
KF129減速機使用說明:
KF129減速機警告說明:由于KF129減速機發熱或KF129減速機油溫過高可能引起燙傷;對KF129減速機進行操作前先冷卻;擰出油位檢查螺栓和放油螺栓時要格外小心。
KF129減速機注意事項:若未注入正確的KF129減速機油則可能造成潤滑油性能失效,可能造成財產損失;合成潤滑油不可能相互混用并不可與礦物潤滑油混用;礦物油用作標準的潤滑油,不能用于特殊行業。
KF129減速機提示事項:油位檢查螺栓、放油螺栓、以及透氣閥的位置在安裝位置上,要參見KF129減速機說明書安裝位置章節中的內容。
KF129減速機的螺母:立式安裝KF129減速機輸出法蘭螺母規格M16;KF129減速機螺母/螺母擰緊扭矩強度等級10.9。伺服電機減速機
KF129減速機危險使用說明:驅動裝置意外啟動會造成擠傷,可能造成重傷或死亡;開始工作前,應先斷開減速電機的電源并且采取措施防止意外接通!
KF129減速機型號:
WKF127-Y112M4,WKF127-Y11SKF,WKF127-Y132M4,WKF127-Y15SKF,WKF127-Y160M4,WKF127-Y18.5SKF,WKF127-Y180M4,WKF127-Y200M4,WKF127-Y225M4,WKF127-Y22SKF,WKF127-Y250M4,WKF127-Y280M4,WKF127-Y30SKF,WKF127-Y37SKF,WKF127-Y45SKF,WKF127-Y4SKF,WKF127-Y5.5SKF,WKF127-Y55SKF,WKF127-Y7.5SKF,WKF127-Y75SKF,WKF127-YB112M4,WKF127-YB132M4,WKF127-YB160M4,WKF127-YB180M4,WKF127-YB200M4,WKF127-YB225M4,WKF127-YB250M4,WKF127-YB280M4,WKF127-YDP112M4,WKF127-YDP132M4,WKF127-YDP160M4,WKF127-YDP180M4,WKF127-YDP200M4,WKF127-YDP225M4,WKF127-YDP250M4,WKF127-YDP280M4,WKF127-YE112M4,WKF127-YE132M4,WKF127-YE160M4,WKF127-YE180M4,WKF127-YE200M4,WKF127-YE225M4,WKF127-YE250M4,WKF127-YE280M4,WKF127-YEJ112M4,WKF127-YEJ132M4,WKF127-YEJ160M4,WKF127-YEJ180M4,WKF127-YEJ200M4,WKF127-YEJ225M4,WKF127-YEJ250M4,WKF127-YEJ280M4,WKF127-YEJB112M4,WKF127-YEJB132M4,WKF127-YEJB160M4,WKF127-YEJB180M4,WKF127-YEJB200M4,WKF127-YEJB225M4,WKF127-YEJB250M4,WKF127-YEJB280M4,WKF127-YP112M4,WKF127-YP132M4,WKF127-YP160M4,WKF127-YP180M4,WKF127-YP200M4,WKF127-YP225M4,WKF127-YP250M4,WKF127-YP280M4,WKF127-YPB112M4,WKF127-YPB132M4,WKF127-YPB160M4,WKF127-YPB180M4,WKF127-YPB200M4,WKF127-YPB225M4,WKF127-YPB250M4,WKF127-YPB280M4,WKF127-YPE112M4,WKF127-YPE132M4,WKF127-YPE160M4,WKF127-YPE180M4,WKF127-YPE200M4,WKF127-YPE225M4,WKF127-YPE250M4,WKF127-YPE280M4,WKF127-YS112M4,WKF127-YS132M4,WKF127-YS160M4,WKF127-YS180M4,WKF127-YS200M4,WKF127-YS225M4,WKF127-YS250M4,WKF127-YS280M4,WKF127-YVB112M4,WKF127-YVB132M4,WKF127-YVB160M4,WKF127-YVB180M4,WKF127-YVB200M4,WKF127-YVB225M4,WKF127-YVB250M4,WKF127-YVB280M4,WKF127-YVP112M4,WKF127-YVP132M4,WKF127-YVP160M4,WKF127-YVP180M4,WKF127-YVP200M4,WKF127-YVP225M4,WKF127-YVP250M4,WKF127-YVP280M4,WKF127-YVPEJ112M4,WKF127-YVPEJ132M4,WKF127-YVPEJ160M4,WKF127-YVPEJ180M4,WKF127-YVPEJ200M4,WKF127-YVPEJ225M4,WKF127-YVPEJ250M4,WKF127-YVPEJ280M4,AKF127-Y112M4,AKF127-Y11SKF,AKF127-Y132M4,AKF127-Y15SKF,AKF127-Y160M4,AKF127-Y18.5SKF,AKF127-Y180M4,AKF127-Y200M4,AKF127-Y225M4,AKF127-Y22SKF,AKF127-Y250M4,AKF127-Y280M4,AKF127-Y30SKF,AKF127-Y37SKF,AKF127-Y45SKF,AKF127-Y4SKF,AKF127-Y5.5SKF,AKF127-Y55SKF,AKF127-Y7.5SKF,AKF127-Y75SKF,AKF127-YB112M4,AKF127-YB132M4,AKF127-YB160M4,AKF127-YB180M4,AKF127-YB200M4,AKF127-YB225M4,AKF127-YB250M4,AKF127-YB280M4,AKF127-YDP112M4,AKF127-YDP132M4,AKF127-YDP160M4,AKF127-YDP180M4,AKF127-YDP200M4,AKF127-YDP225M4,AKF127-YDP250M4,AKF127-YDP280M4,AKF127-YE112M4,AKF127-YE132M4,AKF127-YE160M4,AKF127-YE180M4,AKF127-YE200M4,AKF127-YE225M4,AKF127-YE250M4,AKF127-YE280M4,AKF127-YEJ112M4,AKF127-YEJ132M4,AKF127-YEJ160M4,AKF127-YEJ180M4,AKF127-YEJ200M4,AKF127-YEJ225M4,AKF127-YEJ250M4,AKF127-YEJ280M4,AKF127-YEJB112M4,AKF127-YEJB132M4,AKF127-YEJB160M4,AKF127-YEJB180M4,AKF127-YEJB200M4,AKF127-YEJB225M4,AKF127-YEJB250M4,AKF127-YEJB280M4,AKF127-YP112M4,AKF127-YP132M4,AKF127-YP160M4,AKF127-YP180M4,AKF127-YP200M4,AKF127-YP225M4,AKF127-YP250M4,AKF127-YP280M4,AKF127-YPB112M4,AKF127-YPB132M4,AKF127-YPB160M4,AKF127-YPB180M4,AKF127-YPB200M4,AKF127-YPB225M4,AKF127-YPB250M4,AKF127-YPB280M4,AKF127-YPE112M4,AKF127-YPE132M4,AKF127-YPE160M4,AKF127-YPE180M4,AKF127-YPE200M4,AKF127-YPE225M4,AKF127-YPE250M4,AKF127-YPE280M4,AKF127-YS112M4,AKF127-YS132M4,AKF127-YS160M4,AKF127-YS180M4,AKF127-YS200M4,AKF127-YS225M4,AKF127-YS250M4,AKF127-YS280M4,AKF127-YVB112M4,AKF127-YVB132M4,AKF127-YVB160M4,AKF127-YVB180M4,AKF127-YVB200M4,AKF127-YVB225M4,AKF127-YVB250M4,AKF127-YVB280M4,AKF127-YVP112M4,AKF127-YVP132M4,AKF127-YVP160M4,AKF127-YVP180M4,AKF127-YVP200M4,AKF127-YVP225M4,AKF127-YVP250M4,AKF127-YVP280M4,AKF127-YVPEJ112M4,AKF127-YVPEJ132M4,AKF127-YVPEJ160M4,AKF127-YVPEJ180M4,AKF127-YVPEJ200M4,AKF127-YVPEJ225M4,AKF127-YVPEJ250M4,AKF127-YVPEJ280M4,NKF127-Y112M4,NKF127-Y11SKF,NKF127-Y132M4,NKF127-Y15SKF,NKF127-Y160M4,NKF127-Y18.5SKF,NKF127-Y180M4,NKF127-Y200M4,NKF127-Y225M4,NKF127-Y22SKF,NKF127-Y250M4,NKF127-Y280M4,NKF127-Y30SKF,NKF127-Y37SKF,NKF127-Y45SKF,NKF127-Y4SKF,NKF127-Y5.5SKF,NKF127-Y55SKF,NKF127-Y7.5SKF,NKF127-Y75SKF,NKF127-YB112M4,NKF127-YB132M4,NKF127-YB160M4,NKF127-YB180M4,NKF127-YB200M4,NKF127-YB225M4,NKF127-YB250M4,NKF127-YB280M4,NKF127-YDP112M4,NKF127-YDP132M4,NKF127-YDP160M4,NKF127-YDP180M4,NKF127-YDP200M4,NKF127-YDP225M4,NKF127-YDP250M4,NKF127-YDP280M4,NKF127-YE112M4,NKF127-YE132M4,NKF127-YE160M4,NKF127-YE180M4,NKF127-YE200M4,NKF127-YE225M4,NKF127-YE250M4,NKF127-YE280M4,NKF127-YEJ112M4,NKF127-YEJ132M4,NKF127-YEJ160M4,NKF127-YEJ180M4,NKF127-YEJ200M4,NKF127-YEJ225M4,NKF127-YEJ250M4,NKF127-YEJ280M4,NKF127-YEJB112M4,NKF127-YEJB132M4,NKF127-YEJB160M4,NKF127-YEJB180M4,NKF127-YEJB200M4,NKF127-YEJB225M4,NKF127-YEJB250M4,NKF127-YEJB280M4,NKF127-YP112M4,NKF127-YP132M4,NKF127-YP160M4,NKF127-YP180M4,NKF127-YP200M4,NKF127-YP225M4,NKF127-YP250M4,NKF127-YP280M4,NKF127-YPB112M4,NKF127-YPB132M4,NKF127-YPB160M4,NKF127-YPB180M4,NKF127-YPB200M4,NKF127-YPB225M4,NKF127-YPB250M4,NKF127-YPB280M4,NKF127-YPE112M4,NKF127-YPE132M4,NKF127-YPE160M4,NKF127-YPE180M4,NKF127-YPE200M4,NKF127-YPE225M4,NKF127-YPE250M4,NKF127-YPE280M4,NKF127-YS112M4,NKF127-YS132M4,NKF127-YS160M4,NKF127-YS180M4,NKF127-YS200M4,NKF127-YS225M4,NKF127-YS250M4,NKF127-YS280M4,NKF127-YVB112M4,NKF127-YVB132M4,NKF127-YVB160M4,NKF127-YVB180M4,NKF127-YVB200M4,NKF127-YVB225M4,NKF127-YVB250M4,NKF127-YVB280M4,NKF127-YVP112M4,NKF127-YVP132M4,NKF127-YVP160M4,NKF127-YVP180M4,NKF127-YVP200M4,NKF127-YVP225M4,NKF127-YVP250M4,NKF127-YVP280M4,NKF127-YVPEJ112M4,NKF127-YVPEJ132M4,NKF127-YVPEJ160M4,NKF127-YVPEJ180M4,NKF127-YVPEJ200M4,NKF127-YVPEJ225M4,NKF127-YVPEJ250M4,NKF127-YVPEJ280M4,SKF127-Y112M4,SKF127-Y11SKF,SKF127-Y132M4,SKF127-Y15SKF,SKF127-Y160M4,SKF127-Y18.5SKF,SKF127-Y180M4,SKF127-Y200M4,SKF127-Y225M4,SKF127-Y22SKF,SKF127-Y250M4,SKF127-Y280M4,SKF127-Y30SKF,SKF127-Y37SKF,SKF127-Y45SKF,SKF127-Y4SKF,SKF127-Y5.5SKF,SKF127-Y55SKF,SKF127-Y7.5SKF,SKF127-Y75SKF,SKF127-YB112M4,SKF127-YB132M4,SKF127-YB160M4,SKF127-YB180M4,SKF127-YB200M4,SKF127-YB225M4,SKF127-YB250M4,SKF127-YB280M4,SKF127-YDP112M4,SKF127-YDP132M4,SKF127-YDP160M4,SKF127-YDP180M4,SKF127-YDP200M4,SKF127-YDP225M4,SKF127-YDP250M4,SKF127-YDP280M4,SKF127-YE112M4,SKF127-YE132M4,SKF127-YE160M4,SKF127-YE180M4,SKF127-YE200M4,SKF127-YE225M4,SKF127-YE250M4,SKF127-YE280M4,SKF127-YEJ112M4,SKF127-YEJ132M4,SKF127-YEJ160M4,SKF127-YEJ180M4,SKF127-YEJ200M4,SKF127-YEJ225M4,SKF127-YEJ250M4,SKF127-YEJ280M4,SKF127-YEJB112M4,SKF127-YEJB132M4,SKF127-YEJB160M4,SKF127-YEJB180M4,SKF127-YEJB200M4,SKF127-YEJB225M4,SKF127-YEJB250M4,SKF127-YEJB280M4,SKF127-YP112M4,SKF127-YP132M4,SKF127-YP160M4,SKF127-YP180M4,SKF127-YP200M4,SKF127-YP225M4,SKF127-YP250M4,SKF127-YP280M4,SKF127-YPB112M4,SKF127-YPB132M4,SKF127-YPB160M4,SKF127-YPB180M4,SKF127-YPB200M4,SKF127-YPB225M4,SKF127-YPB250M4,SKF127-YPB280M4,SKF127-YPE112M4,SKF127-YPE132M4,SKF127-YPE160M4,SKF127-YPE180M4,SKF127-YPE200M4,SKF127-YPE225M4,SKF127-YPE250M4,SKF127-YPE280M4,SKF127-YS112M4,SKF127-YS132M4,SKF127-YS160M4,SKF127-YS180M4,SKF127-YS200M4,SKF127-YS225M4,SKF127-YS250M4,SKF127-YS280M4,SKF127-YVB112M4,SKF127-YVB132M4,SKF127-YVB160M4,SKF127-YVB180M4,SKF127-YVB200M4,SKF127-YVB225M4,SKF127-YVB250M4,SKF127-YVB280M4,SKF127-YVP112M4,SKF127-YVP132M4,SKF127-YVP160M4,SKF127-YVP180M4,SKF127-YVP200M4,SKF127-YVP225M4,SKF127-YVP250M4,SKF127-YVP280M4,SKF127-YVPEJ112M4,SKF127-YVPEJ132M4,SKF127-YVPEJ160M4,SKF127-YVPEJ180M4,SKF127-YVPEJ200M4,SKF127-YVPEJ225M4,SKF127-YVPEJ250M4,SKF127-YVPEJ280M4,GKF129-Y112M4,GKF129-Y11SKF,GKF129-Y132M4,GKF129-Y15SKF,GKF129-Y160M4,GKF129-Y18.5SKF,GKF129-Y180M4,GKF129-Y200M4,GKF129-Y225M4,GKF129-Y22SKF,GKF129-Y250M4,GKF129-Y280M4,GKF129-Y30SKF,GKF129-Y37SKF,GKF129-Y45SKF,GKF129-Y4SKF,GKF129-Y5.5SKF,GKF129-Y55SKF,GKF129-Y7.5SKF,GKF129-Y75SKF,GKF129-YB112M4,GKF129-YB132M4,GKF129-YB160M4,GKF129-YB180M4,GKF129-YB200M4,GKF129-YB225M4,GKF129-YB250M4,GKF129-YB280M4,GKF129-YDP112M4,GKF129-YDP132M4,GKF129-YDP160M4,GKF129-YDP180M4,GKF129-YDP200M4,GKF129-YDP225M4,GKF129-YDP250M4,GKF129-YDP280M4,GKF129-YE112M4,GKF129-YE132M4,GKF129-YE160M4,GKF129-YE180M4,GKF129-YE200M4,GKF129-YE225M4,GKF129-YE250M4,GKF129-YE280M4,GKF129-YEJ112M4,GKF129-YEJ132M4,GKF129-YEJ160M4,GKF129-YEJ180M4,GKF129-YEJ200M4,GKF129-YEJ225M4,GKF129-YEJ250M4,GKF129-YEJ280M4,GKF129-YEJB112M4,GKF129-YEJB132M4,GKF129-YEJB160M4,GKF129-YEJB180M4,GKF129-YEJB200M4,GKF129-YEJB225M4,GKF129-YEJB250M4,GKF129-YEJB280M4,GKF129-YP112M4,GKF129-YP132M4,GKF129-YP160M4,GKF129-YP180M4,GKF129-YP200M4,GKF129-YP225M4,GKF129-YP250M4,GKF129-YP280M4,GKF129-YPB112M4,GKF129-YPB132M4,GKF129-YPB160M4,GKF129-YPB180M4,GKF129-YPB200M4,GKF129-YPB225M4,GKF129-YPB250M4,GKF129-YPB280M4,GKF129-YPE112M4,GKF129-YPE132M4,GKF129-YPE160M4,GKF129-YPE180M4,GKF129-YPE200M4,GKF129-YPE225M4,GKF129-YPE250M4,GKF129-YPE280M4,GKF129-YS112M4,GKF129-YS132M4,GKF129-YS160M4,GKF129-YS180M4,GKF129-YS200M4,GKF129-YS225M4,GKF129-YS250M4,GKF129-YS280M4,GKF129-YVB112M4,GKF129-YVB132M4,GKF129-YVB160M4,GKF129-YVB180M4,GKF129-YVB200M4,GKF129-YVB225M4,GKF129-YVB250M4,GKF129-YVB280M4,GKF129-YVP112M4,GKF129-YVP132M4,GKF129-YVP160M4,GKF129-YVP180M4,GKF129-YVP200M4,GKF129-YVP225M4,GKF129-YVP250M4,GKF129-YVP280M4,GKF129-YVPEJ112M4,GKF129-YVPEJ132M4,GKF129-YVPEJ160M4,GKF129-YVPEJ180M4,GKF129-YVPEJ200M4,GKF129-YVPEJ225M4,GKF129-YVPEJ250M4,GKF129-YVPEJ280M4。
KF129減速機生產廠家展示:看廠請聯系微信13827261050,獲取位置,需提前一天預約http://njxyx.com/product/list-kfxiliejiansuji-cn.html
推薦類似型號:K129減速機
關鍵詞:帶伺服減速機_伺服電機減速機_伺服電機減速器_伺服減速器_大扭力減速機_大扭力減速器_交流減速機_GKF系列減速機_KF系列減速機_伺服電機減速機一體機_伺服減速機一體機_KF系列減速器
KF系列齒輪減速電機型號:KF39減速機,KF49減速機,KF59減速機,KF69減速機,KF79減速機,KF89減速機,KF99減速機,KF109減速機,KF129減速機,KF159減速機,KF167減速機,KF187減速機
KF系列直角減速機可配變頻電機,剎車電機,防爆電機,伺服電機,交流電機,直流電機,三相電機,單相電機 0.12KW-200KW之間
如需工程師幫選型,請加微信13827261050,留言告知工程師參數要求
