FA79R39減速機銘牌參數說明解讀含義:有關型號描述的詳細情況及其他信息可以參閱本業附件下載中的FA79R39減速機選型樣本。
FA79R39-Y0.55KW-4P-367-M5-180°
FA/R:系列代號
79/39:減速機規格代號
Y:電機
0.55KW:電機功率
4P:電機級數
367:減速機傳動比
M5:減速機安裝位置
180°:接線盒位置
FA79R39減速機電機使用環境要求:
環境溫度-5~40C;環境濕度85%;海拔高度1000m以下。齒輪減速電機
請勿在爆炸環境、易燃性氣體環境、腐蝕性環境以及漏水的環境下使用此減速電機;
請勿強行彎曲、拉扯或夾住電源、電纜線和電機導線;
電機安裝完成后,必須使用接地線良好接地,接地線位置位于接線盒上面;
安裝、連接、檢查等須由專業技術人員進行;
安裝環境需干燥且通風良好,周圍溫度-5~40℃之間若需高溫或低溫環境下運行,請?zhí)貏e說明;
齒輪減速電機需安裝在平整且堅固的機座上。
備注:大部分電機在50Hz交流電下的聲壓級都不超過70dB(A)。平行軸斜齒輪減速機
FA79R39減速機電機使用使用前事項:
收貨后:請立即檢查有無運輸損壞。如有損壞請立即通知運輸公司。必要情況下不得對設備進行調試運行;請檢查產品型號、電機功率、電機額定電壓、安裝方式及出力軸尺寸是否符合要求,如有不符請及時與廠家或經銷商聯系,以便及時處理。
請根據接線盒內的接線圖或者使用說明書與電源電纜進行連接。否則有可能會導致觸電和火災。
請勿過分彎曲、牽拉、夾持電源電纜以及電機導線。否則有可能會導致觸電。請將接地用端子切實接地。否則有可能會導致觸電。
請務必使用銘牌上記載的電源。否則有可能會損壞電機、引發火災。分體減速機電機
FA79R39減速電機型號:
YQFA77R37-Y0.12KW,YQFA77R37-Y0.18KW,YQFA77R37-Y0.25KW,YQFA77R37-Y0.37KW,YQFA77R37-Y0.55KW,YQFA77R37-Y0.75KW,YQFA77R37-Y63M4,YQFA77R37-Y71M4,YQFA77R37-Y80M4,YQFA77RF37-Y63M4,YQFA77RF37-Y71M4,YQFA77RF37-Y80M4,YQFA77RF37-YB63M4,YQFA77RF37-YB71M4,YQFA77RF37-YB80M4,YQFA77RF37-YDP63M4,YQFA77RF37-YDP71M4,YQFA77RF37-YDP80M4,YQFA77RF37-YE63M4,YQFA77RF37-YE71M4,YQFA77RF37-YE80M4,YQFA77RF37-YEJ63M4,YQFA77RF37-YEJ71M4,YQFA77RF37-YEJ80M4,YQFA77RF37-YEJB63M4,YQFA77RF37-YEJB71M4,YQFA77RF37-YEJB80M4,YQFA77RF37-YP63M4,YQFA77RF37-YP71M4,YQFA77RF37-YP80M4,YQFA77RF37-YPB63M4,YQFA77RF37-YPB71M4,YQFA77RF37-YPB80M4,YQFA77RF37-YPE63M4,YQFA77RF37-YPE71M4,YQFA77RF37-YPE80M4,YQFA77RF37-YS63M4,YQFA77RF37-YS71M4,YQFA77RF37-YS80M4,YQFA77RF37-YVB63M4,YQFA77RF37-YVB71M4,YQFA77RF37-YVB80M4,YQFA77RF37-YVP63M4,YQFA77RF37-YVP71M4,YQFA77RF37-YVP80M4,YQFA77RF37-YVPEJ63M4,YQFA77RF37-YVPEJ71M4,YQFA77RF37-YVPEJ80M4,WFA77R37-Y0.12KW,WFA77R37-Y0.18KW,WFA77R37-Y0.25KW,WFA77R37-Y0.37KW,WFA77R37-Y0.55KW,WFA77R37-Y0.75KW,WFA77R37-Y63M4,WFA77R37-Y71M4,WFA77R37-Y80M4,WFA77RF37-Y63M4,WFA77RF37-Y71M4,WFA77RF37-Y80M4,WFA77RF37-YB63M4,WFA77RF37-YB71M4,WFA77RF37-YB80M4,WFA77RF37-YDP63M4,WFA77RF37-YDP71M4,WFA77RF37-YDP80M4,WFA77RF37-YE63M4,WFA77RF37-YE71M4,WFA77RF37-YE80M4,WFA77RF37-YEJ63M4,WFA77RF37-YEJ71M4,WFA77RF37-YEJ80M4,WFA77RF37-YEJB63M4,WFA77RF37-YEJB71M4,WFA77RF37-YEJB80M4,WFA77RF37-YP63M4,WFA77RF37-YP71M4,WFA77RF37-YP80M4,WFA77RF37-YPB63M4,WFA77RF37-YPB71M4,WFA77RF37-YPB80M4,WFA77RF37-YPE63M4,WFA77RF37-YPE71M4,WFA77RF37-YPE80M4,WFA77RF37-YS63M4,WFA77RF37-YS71M4,WFA77RF37-YS80M4,WFA77RF37-YVB63M4,WFA77RF37-YVB71M4,WFA77RF37-YVB80M4,WFA77RF37-YVP63M4,WFA77RF37-YVP71M4,WFA77RF37-YVP80M4,WFA77RF37-YVPEJ63M4,WFA77RF37-YVPEJ71M4,WFA77RF37-YVPEJ80M4,XDFA77R37-Y0.12KW,XDFA77R37-Y0.18KW,XDFA77R37-Y0.25KW,XDFA77R37-Y0.37KW,XDFA77R37-Y0.55KW,XDFA77R37-Y0.75KW,XDFA77R37-Y63M4,XDFA77R37-Y71M4,XDFA77R37-Y80M4,XDFA77RF37-Y63M4,XDFA77RF37-Y71M4,XDFA77RF37-Y80M4,XDFA77RF37-YB63M4,XDFA77RF37-YB71M4,XDFA77RF37-YB80M4,XDFA77RF37-YDP63M4,XDFA77RF37-YDP71M4,XDFA77RF37-YDP80M4,XDFA77RF37-YE63M4,XDFA77RF37-YE71M4,XDFA77RF37-YE80M4,XDFA77RF37-YEJ63M4,XDFA77RF37-YEJ71M4,XDFA77RF37-YEJ80M4,XDFA77RF37-YEJB63M4,XDFA77RF37-YEJB71M4,XDFA77RF37-YEJB80M4,XDFA77RF37-YP63M4,XDFA77RF37-YP71M4,XDFA77RF37-YP80M4,XDFA77RF37-YPB63M4,XDFA77RF37-YPB71M4,XDFA77RF37-YPB80M4,XDFA77RF37-YPE63M4,XDFA77RF37-YPE71M4,XDFA77RF37-YPE80M4,XDFA77RF37-YS63M4,XDFA77RF37-YS71M4,XDFA77RF37-YS80M4,XDFA77RF37-YVB63M4,XDFA77RF37-YVB71M4,XDFA77RF37-YVB80M4,XDFA77RF37-YVP63M4,XDFA77RF37-YVP71M4,XDFA77RF37-YVP80M4,XDFA77RF37-YVPEJ63M4,XDFA77RF37-YVPEJ71M4,XDFA77RF37-YVPEJ80M4,SFA77R37-Y0.12KW,SFA77R37-Y0.18KW,SFA77R37-Y0.25KW,SFA77R37-Y0.37KW,SFA77R37-Y0.55KW,SFA77R37-Y0.75KW,SFA77R37-Y63M4,SFA77R37-Y71M4,SFA77R37-Y80M4,SFA77RF37-Y63M4,SFA77RF37-Y71M4,SFA77RF37-Y80M4,SFA77RF37-YB63M4,SFA77RF37-YB71M4,SFA77RF37-YB80M4,SFA77RF37-YDP63M4,SFA77RF37-YDP71M4,SFA77RF37-YDP80M4,SFA77RF37-YE63M4,SFA77RF37-YE71M4,SFA77RF37-YE80M4,SFA77RF37-YEJ63M4,SFA77RF37-YEJ71M4,SFA77RF37-YEJ80M4,SFA77RF37-YEJB63M4,SFA77RF37-YEJB71M4,SFA77RF37-YEJB80M4,SFA77RF37-YP63M4,SFA77RF37-YP71M4,SFA77RF37-YP80M4,SFA77RF37-YPB63M4,SFA77RF37-YPB71M4,SFA77RF37-YPB80M4,SFA77RF37-YPE63M4,SFA77RF37-YPE71M4,SFA77RF37-YPE80M4,SFA77RF37-YS63M4,SFA77RF37-YS71M4,SFA77RF37-YS80M4,SFA77RF37-YVB63M4,SFA77RF37-YVB71M4,SFA77RF37-YVB80M4,SFA77RF37-YVP63M4,SFA77RF37-YVP71M4,SFA77RF37-YVP80M4,SFA77RF37-YVPEJ63M4,SFA77RF37-YVPEJ71M4,SFA77RF37-YVPEJ80M4,JCFA77R37-Y0.12KW,JCFA77R37-Y0.18KW,JCFA77R37-Y0.25KW,JCFA77R37-Y0.37KW,JCFA77R37-Y0.55KW,JCFA77R37-Y0.75KW,JCFA77R37-Y63M4,JCFA77R37-Y71M4,JCFA77R37-Y80M4,JCFA77RF37-Y63M4,JCFA77RF37-Y71M4,JCFA77RF37-Y80M4,JCFA77RF37-YB63M4,JCFA77RF37-YB71M4,JCFA77RF37-YB80M4,JCFA77RF37-YDP63M4,JCFA77RF37-YDP71M4,JCFA77RF37-YDP80M4,JCFA77RF37-YE63M4,JCFA77RF37-YE71M4,JCFA77RF37-YE80M4,JCFA77RF37-YEJ63M4,JCFA77RF37-YEJ71M4,JCFA77RF37-YEJ80M4,JCFA77RF37-YEJB63M4,JCFA77RF37-YEJB71M4,JCFA77RF37-YEJB80M4,JCFA77RF37-YP63M4,JCFA77RF37-YP71M4,JCFA77RF37-YP80M4,JCFA77RF37-YPB63M4,JCFA77RF37-YPB71M4,JCFA77RF37-YPB80M4,JCFA77RF37-YPE63M4,JCFA77RF37-YPE71M4,JCFA77RF37-YPE80M4,JCFA77RF37-YS63M4,JCFA77RF37-YS71M4,JCFA77RF37-YS80M4,JCFA77RF37-YVB63M4,JCFA77RF37-YVB71M4,JCFA77RF37-YVB80M4,JCFA77RF37-YVP63M4,JCFA77RF37-YVP71M4,JCFA77RF37-YVP80M4,JCFA77RF37-YVPEJ63M4,JCFA77RF37-YVPEJ71M4,JCFA77RF37-YVPEJ80M4,NFA77R37-Y0.12KW,NFA77R37-Y0.18KW,NFA77R37-Y0.25KW,NFA77R37-Y0.37KW,NFA77R37-Y0.55KW,NFA77R37-Y0.75KW,NFA77R37-Y63M4,NFA77R37-Y71M4,NFA77R37-Y80M4,NFA77RF37-Y63M4,NFA77RF37-Y71M4,NFA77RF37-Y80M4,NFA77RF37-YB63M4,NFA77RF37-YB71M4,NFA77RF37-YB80M4,NFA77RF37-YDP63M4,NFA77RF37-YDP71M4,NFA77RF37-YDP80M4,NFA77RF37-YE63M4,NFA77RF37-YE71M4,NFA77RF37-YE80M4,NFA77RF37-YEJ63M4,NFA77RF37-YEJ71M4,NFA77RF37-YEJ80M4,NFA77RF37-YEJB63M4,NFA77RF37-YEJB71M4,NFA77RF37-YEJB80M4,NFA77RF37-YP63M4,NFA77RF37-YP71M4,NFA77RF37-YP80M4,NFA77RF37-YPB63M4,NFA77RF37-YPB71M4,NFA77RF37-YPB80M4,NFA77RF37-YPE63M4,NFA77RF37-YPE71M4,NFA77RF37-YPE80M4,NFA77RF37-YS63M4,NFA77RF37-YS71M4,NFA77RF37-YS80M4,NFA77RF37-YVB63M4,NFA77RF37-YVB71M4,NFA77RF37-YVB80M4,NFA77RF37-YVP63M4,NFA77RF37-YVP71M4,NFA77RF37-YVP80M4,NFA77RF37-YVPEJ63M4,NFA77RF37-YVPEJ71M4,NFA77RF37-YVPEJ80M4,AFA77R37-Y0.12KW,AFA77R37-Y0.18KW,AFA77R37-Y0.25KW,AFA77R37-Y0.37KW,AFA77R37-Y0.55KW,AFA77R37-Y0.75KW,AFA77R37-Y63M4,AFA77R37-Y71M4,AFA77R37-Y80M4,AFA77RF37-Y63M4,AFA77RF37-Y71M4,AFA77RF37-Y80M4,AFA77RF37-YB63M4,AFA77RF37-YB71M4,AFA77RF37-YB80M4,AFA77RF37-YDP63M4,AFA77RF37-YDP71M4,AFA77RF37-YDP80M4,AFA77RF37-YE63M4,AFA77RF37-YE71M4,AFA77RF37-YE80M4,AFA77RF37-YEJ63M4,AFA77RF37-YEJ71M4,AFA77RF37-YEJ80M4,AFA77RF37-YEJB63M4,AFA77RF37-YEJB71M4,AFA77RF37-YEJB80M4,AFA77RF37-YP63M4,AFA77RF37-YP71M4,AFA77RF37-YP80M4,AFA77RF37-YPB63M4,AFA77RF37-YPB71M4,AFA77RF37-YPB80M4,AFA77RF37-YPE63M4,AFA77RF37-YPE71M4,AFA77RF37-YPE80M4,AFA77RF37-YS63M4,AFA77RF37-YS71M4,AFA77RF37-YS80M4,AFA77RF37-YVB63M4,AFA77RF37-YVB71M4,AFA77RF37-YVB80M4,AFA77RF37-YVP63M4,AFA77RF37-YVP71M4,AFA77RF37-YVP80M4,AFA77RF37-YVPEJ63M4,AFA77RF37-YVPEJ71M4,AFA77RF37-YVPEJ80M4,FWA77RW37-Y0.12KW,FWA77RW37-Y0.18KW,FWA77RW37-Y0.25KW,FWA77RW37-Y0.37KW,FWA77RW37-Y0.55KW,FWA77RW37-Y0.75KW,FWA77RW37-Y63M4,FWA77RW37-Y71M4,FWA77RW37-Y80M4,FWA77RWFA37-Y63M4,FWA77RWFA37-Y71M4,FWA77RWFA37-Y80M4,FWA77RWFA37-YB63M4,FWA77RWFA37-YB71M4,FWA77RWFA37-YB80M4,FWA77RWFA37-YDP63M4,FWA77RWFA37-YDP71M4,FWA77RWFA37-YDP80M4,FWA77RWFA37-YE63M4,FWA77RWFA37-YE71M4,FWA77RWFA37-YE80M4,FWA77RWFA37-YEJ63M4,FWA77RWFA37-YEJ71M4,FWA77RWFA37-YEJ80M4,FWA77RWFA37-YEJB63M4,FWA77RWFA37-YEJB71M4,FWA77RWFA37-YEJB80M4,FWA77RWFA37-YP63M4,FWA77RWFA37-YP71M4,FWA77RWFA37-YP80M4,FWA77RWFA37-YPB63M4,FWA77RWFA37-YPB71M4,FWA77RWFA37-YPB80M4,FWA77RWFA37-YPE63M4,FWA77RWFA37-YPE71M4,FWA77RWFA37-YPE80M4,FWA77RWFA37-YS63M4,FWA77RWFA37-YS71M4,FWA77RWFA37-YS80M4,FWA77RWFA37-YVB63M4,FWA77RWFA37-YVB71M4,FWA77RWFA37-YVB80M4,FWA77RWFA37-YVP63M4,FWA77RWFA37-YVP71M4,FWA77RWFA37-YVP80M4,FWA77RWFA37-YVPEJ63M4,FWA77RWFA37-YVPEJ71M4,FWA77RWFA37-YVPEJ80M4,FA79R39-Y0.12KW,FA79R39-Y0.18KW,FA79R39-Y0.25KW,FA79R39-Y0.39KW,FA79R39-Y0.55KW,FA79R39-Y0.75KW,FA79R39-Y63M4,FA79R39-Y71M4,FA79R39-Y80M4,FA79RF39-Y63M4,FA79RF39-Y71M4,FA79RF39-Y80M4,FA79RF39-YB63M4,FA79RF39-YB71M4,FA79RF39-YB80M4,FA79RF39-YDP63M4,FA79RF39-YDP71M4,FA79RF39-YDP80M4,FA79RF39-YE63M4,FA79RF39-YE71M4,FA79RF39-YE80M4,FA79RF39-YEJ63M4,FA79RF39-YEJ71M4,FA79RF39-YEJ80M4,FA79RF39-YEJB63M4,FA79RF39-YEJB71M4,FA79RF39-YEJB80M4,FA79RF39-YP63M4,FA79RF39-YP71M4,FA79RF39-YP80M4,FA79RF39-YPB63M4,FA79RF39-YPB71M4,FA79RF39-YPB80M4,FA79RF39-YPE63M4,FA79RF39-YPE71M4,FA79RF39-YPE80M4,FA79RF39-YS63M4,FA79RF39-YS71M4,FA79RF39-YS80M4,FA79RF39-YVB63M4,FA79RF39-YVB71M4,FA79RF39-YVB80M4,FA79RF39-YVP63M4,FA79RF39-YVP71M4,FA79RF39-YVP80M4,FA79RF39-YVPEJ63M4,FA79RF39-YVPEJ71M4,FA79RF39-YVPEJ80M4。
FA79R39減速電機生產廠家展示:看廠請聯系微信13827261050,獲取位置,需提前一天預約http://njxyx.com/product/list-faxiliejiansuji-cn.html
推薦型號:F79減速機
關鍵詞:分體減速機帶電機_分體電機減速機_分體減速機_分體電機_FA系列減速機_FA型減速機_GFA系列減速機_FA系列減速器_FA系列減速機一體機生產廠家
FA系列齒輪減速電機型號:FA29減速機,FA39減速機,FA49減速機,FA69減速機,FA79減速機,FA89減速機,FA99減速機,FA109減速機,FA129減速機,FA159減速機
FA系列電動機減速機可配變頻電機,剎車電機,防爆電機,伺服電機,交流電機,直流電機,三相電機,單相電機 0.12KW-132KW之間
如需工程師幫選型,請加微信13827261050,留言告知工程師參數要求
