S89R59減速機銘牌參數說明解讀含義:有關型號描述的詳細情況及其他信息可以參閱本業附件下載中的S89R59減速機選型樣本。
S89R59-Y0.37KW-4P-930-M2-90°
S/R:系列代號
89/59:減速機規格代號
Y:電機
0.37KW:電機功率
4P:電機級數
930:減速機傳動比
M2:減速機安裝位置
90°:接線盒位置
S89R59減速機電機接線注意事項:
電機本體并不附帶保護裝置。按照電氣設備技術標準的規定,必須安裝過載保護裝置。同時,推薦安裝漏電斷路器等其它保護裝置。否則有可能會導致?lián)p傷、觸電、火災、燒傷。齒輪減速電機
請將接線時的電壓壓降控制在2%以內,接線距離過長,可導致電壓壓降過大,電機可能無法啟動。
進行反轉時,請務必先暫停,然后開始反轉。逆向制動引起的正反運轉可能會損壞裝置。
附帶制動器時,制動線圈應與電機繞組同步通斷。
測定絕緣電阻時,請勿觸摸端子。否則有可能會導致觸電。
若繞組通制動不通,電機會卡死燒機;若制動通繞組不通,有可能會導致線圈燒毀、火災。自鎖減速機
S89R59減速機電機噪音故障維修:
風葉擦風罩將,風葉/風罩扳正,或更換變型零部件;
軸承壞,更換軸承;
底板松動,擰緊固定螺栓;
電機缺相運行:電源接觸不良,修復觸點及電源線路;
電機缺相運行:線圈斷路,更換定子線圈;
氣隙不均,檢查并校正軸承座配合/更換端蓋或法蘭;
定轉子擦,更換電機;
轉子不平衡量大,重新校平衡;S系列減速機
轉子斷條,更換轉子;線圈內有一個線苞嵌反,更換定子線圈。
S89R59減速電機型號:
YQS87R57-Y63M4,YQS87R57-Y71M4,YQS87R57-Y80M4,YQS87R57-Y90M4,YQS87RF57-Y0.12KW,YQS87RF57-Y0.18KW,YQS87RF57-Y0.25KW,YQS87RF57-Y0.37KW,YQS87RF57-Y0.55KW,YQS87RF57-Y0.75KW,YQS87RF57-Y1.1KW,YQS87RF57-Y1.5KW,YQS87RF57-Y63M4,YQS87RF57-Y71M4,YQS87RF57-Y80M4,YQS87RF57-Y90M4,YQS87RF57-YB63M4,YQS87RF57-YB71M4,YQS87RF57-YB80M4,YQS87RF57-YB90S4,YQS87RF57-YDP63M4,YQS87RF57-YDP71M4,YQS87RF57-YDP80M4,YQS87RF57-YDP90S4,YQS87RF57-YE63M4,YQS87RF57-YE71M4,YQS87RF57-YE80M4,YQS87RF57-YE90S4,YQS87RF57-YEJ63M4,YQS87RF57-YEJ71M4,YQS87RF57-YEJ80M4,YQS87RF57-YEJ90S4,YQS87RF57-YEJB63M4,YQS87RF57-YEJB71M4,YQS87RF57-YEJB80M4,YQS87RF57-YEJB90S4,YQS87RF57-YP63M4,YQS87RF57-YP71M4,YQS87RF57-YP80M4,YQS87RF57-YP90S4,YQS87RF57-YPB63M4,YQS87RF57-YPB71M4,YQS87RF57-YPB80M4,YQS87RF57-YPB90S4,YQS87RF57-YPE63M4,YQS87RF57-YPE71M4,YQS87RF57-YPE80M4,YQS87RF57-YPE90S4,YQS87RF57-YS63M4,YQS87RF57-YS71M4,YQS87RF57-YS80M4,YQS87RF57-YS90S4,YQS87RF57-YVB63M4,YQS87RF57-YVB71M4,YQS87RF57-YVB80M4,YQS87RF57-YVB90S4,YQS87RF57-YVP63M4,YQS87RF57-YVP71M4,YQS87RF57-YVP80M4,YQS87RF57-YVP90S4,AS87R57-Y63M4,AS87R57-Y71M4,AS87R57-Y80M4,AS87R57-Y90M4,AS87RF57-Y0.12KW,AS87RF57-Y0.18KW,AS87RF57-Y0.25KW,AS87RF57-Y0.37KW,AS87RF57-Y0.55KW,AS87RF57-Y0.75KW,AS87RF57-Y1.1KW,AS87RF57-Y1.5KW,AS87RF57-Y63M4,AS87RF57-Y71M4,AS87RF57-Y80M4,AS87RF57-Y90M4,AS87RF57-YB63M4,AS87RF57-YB71M4,AS87RF57-YB80M4,AS87RF57-YB90S4,AS87RF57-YDP63M4,AS87RF57-YDP71M4,AS87RF57-YDP80M4,AS87RF57-YDP90S4,AS87RF57-YE63M4,AS87RF57-YE71M4,AS87RF57-YE80M4,AS87RF57-YE90S4,AS87RF57-YEJ63M4,AS87RF57-YEJ71M4,AS87RF57-YEJ80M4,AS87RF57-YEJ90S4,AS87RF57-YEJB63M4,AS87RF57-YEJB71M4,AS87RF57-YEJB80M4,AS87RF57-YEJB90S4,AS87RF57-YP63M4,AS87RF57-YP71M4,AS87RF57-YP80M4,AS87RF57-YP90S4,AS87RF57-YPB63M4,AS87RF57-YPB71M4,AS87RF57-YPB80M4,AS87RF57-YPB90S4,AS87RF57-YPE63M4,AS87RF57-YPE71M4,AS87RF57-YPE80M4,AS87RF57-YPE90S4,AS87RF57-YS63M4,AS87RF57-YS71M4,AS87RF57-YS80M4,AS87RF57-YS90S4,AS87RF57-YVB63M4,AS87RF57-YVB71M4,AS87RF57-YVB80M4,AS87RF57-YVB90S4,AS87RF57-YVP63M4,AS87RF57-YVP71M4,AS87RF57-YVP80M4,AS87RF57-YVP90S4,SS87R57-Y63M4,SS87R57-Y71M4,SS87R57-Y80M4,SS87R57-Y90M4,SS87RF57-Y0.12KW,SS87RF57-Y0.18KW,SS87RF57-Y0.25KW,SS87RF57-Y0.37KW,SS87RF57-Y0.55KW,SS87RF57-Y0.75KW,SS87RF57-Y1.1KW,SS87RF57-Y1.5KW,SS87RF57-Y63M4,SS87RF57-Y71M4,SS87RF57-Y80M4,SS87RF57-Y90M4,SS87RF57-YB63M4,SS87RF57-YB71M4,SS87RF57-YB80M4,SS87RF57-YB90S4,SS87RF57-YDP63M4,SS87RF57-YDP71M4,SS87RF57-YDP80M4,SS87RF57-YDP90S4,SS87RF57-YE63M4,SS87RF57-YE71M4,SS87RF57-YE80M4,SS87RF57-YE90S4,SS87RF57-YEJ63M4,SS87RF57-YEJ71M4,SS87RF57-YEJ80M4,SS87RF57-YEJ90S4,SS87RF57-YEJB63M4,SS87RF57-YEJB71M4,SS87RF57-YEJB80M4,SS87RF57-YEJB90S4,SS87RF57-YP63M4,SS87RF57-YP71M4,SS87RF57-YP80M4,SS87RF57-YP90S4,SS87RF57-YPB63M4,SS87RF57-YPB71M4,SS87RF57-YPB80M4,SS87RF57-YPB90S4,SS87RF57-YPE63M4,SS87RF57-YPE71M4,SS87RF57-YPE80M4,SS87RF57-YPE90S4,SS87RF57-YS63M4,SS87RF57-YS71M4,SS87RF57-YS80M4,SS87RF57-YS90S4,SS87RF57-YVB63M4,SS87RF57-YVB71M4,SS87RF57-YVB80M4,SS87RF57-YVB90S4,SS87RF57-YVP63M4,SS87RF57-YVP71M4,SS87RF57-YVP80M4,SS87RF57-YVP90S4,XDS87R57-Y63M4,XDS87R57-Y71M4,XDS87R57-Y80M4,XDS87R57-Y90M4,XDS87RF57-Y0.12KW,XDS87RF57-Y0.18KW,XDS87RF57-Y0.25KW,XDS87RF57-Y0.37KW,XDS87RF57-Y0.55KW,XDS87RF57-Y0.75KW,XDS87RF57-Y1.1KW,XDS87RF57-Y1.5KW,XDS87RF57-Y63M4,XDS87RF57-Y71M4,XDS87RF57-Y80M4,XDS87RF57-Y90M4,XDS87RF57-YB63M4,XDS87RF57-YB71M4,XDS87RF57-YB80M4,XDS87RF57-YB90S4,XDS87RF57-YDP63M4,XDS87RF57-YDP71M4,XDS87RF57-YDP80M4,XDS87RF57-YDP90S4,XDS87RF57-YE63M4,XDS87RF57-YE71M4,XDS87RF57-YE80M4,XDS87RF57-YE90S4,XDS87RF57-YEJ63M4,XDS87RF57-YEJ71M4,XDS87RF57-YEJ80M4,XDS87RF57-YEJ90S4,XDS87RF57-YEJB63M4,XDS87RF57-YEJB71M4,XDS87RF57-YEJB80M4,XDS87RF57-YEJB90S4,XDS87RF57-YP63M4,XDS87RF57-YP71M4,XDS87RF57-YP80M4,XDS87RF57-YP90S4,XDS87RF57-YPB63M4,XDS87RF57-YPB71M4,XDS87RF57-YPB80M4,XDS87RF57-YPB90S4,XDS87RF57-YPE63M4,XDS87RF57-YPE71M4,XDS87RF57-YPE80M4,XDS87RF57-YPE90S4,XDS87RF57-YS63M4,XDS87RF57-YS71M4,XDS87RF57-YS80M4,XDS87RF57-YS90S4,XDS87RF57-YVB63M4,XDS87RF57-YVB71M4,XDS87RF57-YVB80M4,XDS87RF57-YVB90S4,XDS87RF57-YVP63M4,XDS87RF57-YVP71M4,XDS87RF57-YVP80M4,XDS87RF57-YVP90S4,WS87R57-Y63M4,WS87R57-Y71M4,WS87R57-Y80M4,WS87R57-Y90M4,WS87RF57-Y0.12KW,WS87RF57-Y0.18KW,WS87RF57-Y0.25KW,WS87RF57-Y0.37KW,WS87RF57-Y0.55KW,WS87RF57-Y0.75KW,WS87RF57-Y1.1KW,WS87RF57-Y1.5KW,WS87RF57-Y63M4,WS87RF57-Y71M4,WS87RF57-Y80M4,WS87RF57-Y90M4,WS87RF57-YB63M4,WS87RF57-YB71M4,WS87RF57-YB80M4,WS87RF57-YB90S4,WS87RF57-YDP63M4,WS87RF57-YDP71M4,WS87RF57-YDP80M4,WS87RF57-YDP90S4,WS87RF57-YE63M4,WS87RF57-YE71M4,WS87RF57-YE80M4,WS87RF57-YE90S4,WS87RF57-YEJ63M4,WS87RF57-YEJ71M4,WS87RF57-YEJ80M4,WS87RF57-YEJ90S4,WS87RF57-YEJB63M4,WS87RF57-YEJB71M4,WS87RF57-YEJB80M4,WS87RF57-YEJB90S4,WS87RF57-YP63M4,WS87RF57-YP71M4,WS87RF57-YP80M4,WS87RF57-YP90S4,WS87RF57-YPB63M4,WS87RF57-YPB71M4,WS87RF57-YPB80M4,WS87RF57-YPB90S4,WS87RF57-YPE63M4,WS87RF57-YPE71M4,WS87RF57-YPE80M4,WS87RF57-YPE90S4,WS87RF57-YS63M4,WS87RF57-YS71M4,WS87RF57-YS80M4,WS87RF57-YS90S4,WS87RF57-YVB63M4,WS87RF57-YVB71M4,WS87RF57-YVB80M4,WS87RF57-YVB90S4,WS87RF57-YVP63M4,WS87RF57-YVP71M4,WS87RF57-YVP80M4,WS87RF57-YVP90S4,JCS87R57-Y63M4,JCS87R57-Y71M4,JCS87R57-Y80M4,JCS87R57-Y90M4,JCS87RF57-Y0.12KW,JCS87RF57-Y0.18KW,JCS87RF57-Y0.25KW,JCS87RF57-Y0.37KW,JCS87RF57-Y0.55KW,JCS87RF57-Y0.75KW,JCS87RF57-Y1.1KW,JCS87RF57-Y1.5KW,JCS87RF57-Y63M4,JCS87RF57-Y71M4,JCS87RF57-Y80M4,JCS87RF57-Y90M4,JCS87RF57-YB63M4,JCS87RF57-YB71M4,JCS87RF57-YB80M4,JCS87RF57-YB90S4,JCS87RF57-YDP63M4,JCS87RF57-YDP71M4,JCS87RF57-YDP80M4,JCS87RF57-YDP90S4,JCS87RF57-YE63M4,JCS87RF57-YE71M4,JCS87RF57-YE80M4,JCS87RF57-YE90S4,JCS87RF57-YEJ63M4,JCS87RF57-YEJ71M4,JCS87RF57-YEJ80M4,JCS87RF57-YEJ90S4,JCS87RF57-YEJB63M4,JCS87RF57-YEJB71M4,JCS87RF57-YEJB80M4,JCS87RF57-YEJB90S4,JCS87RF57-YP63M4,JCS87RF57-YP71M4,JCS87RF57-YP80M4,JCS87RF57-YP90S4,JCS87RF57-YPB63M4,JCS87RF57-YPB71M4,JCS87RF57-YPB80M4,JCS87RF57-YPB90S4,JCS87RF57-YPE63M4,JCS87RF57-YPE71M4,JCS87RF57-YPE80M4,JCS87RF57-YPE90S4,JCS87RF57-YS63M4,JCS87RF57-YS71M4,JCS87RF57-YS80M4,JCS87RF57-YS90S4,JCS87RF57-YVB63M4,JCS87RF57-YVB71M4,JCS87RF57-YVB80M4,JCS87RF57-YVB90S4,JCS87RF57-YVP63M4,JCS87RF57-YVP71M4,JCS87RF57-YVP80M4,JCS87RF57-YVP90S4,NS87R57-Y63M4,NS87R57-Y71M4,NS87R57-Y80M4,NS87R57-Y90M4,NS87RF57-Y0.12KW,NS87RF57-Y0.18KW,NS87RF57-Y0.25KW,NS87RF57-Y0.37KW,NS87RF57-Y0.55KW,NS87RF57-Y0.75KW,NS87RF57-Y1.1KW,NS87RF57-Y1.5KW,NS87RF57-Y63M4,NS87RF57-Y71M4,NS87RF57-Y80M4,NS87RF57-Y90M4,NS87RF57-YB63M4,NS87RF57-YB71M4,NS87RF57-YB80M4,NS87RF57-YB90S4,NS87RF57-YDP63M4,NS87RF57-YDP71M4,NS87RF57-YDP80M4,NS87RF57-YDP90S4,NS87RF57-YE63M4,NS87RF57-YE71M4,NS87RF57-YE80M4,NS87RF57-YE90S4,NS87RF57-YEJ63M4,NS87RF57-YEJ71M4,NS87RF57-YEJ80M4,NS87RF57-YEJ90S4,NS87RF57-YEJB63M4,NS87RF57-YEJB71M4,NS87RF57-YEJB80M4,NS87RF57-YEJB90S4,NS87RF57-YP63M4,NS87RF57-YP71M4,NS87RF57-YP80M4,NS87RF57-YP90S4,NS87RF57-YPB63M4,NS87RF57-YPB71M4,NS87RF57-YPB80M4,NS87RF57-YPB90S4,NS87RF57-YPE63M4,NS87RF57-YPE71M4,NS87RF57-YPE80M4,NS87RF57-YPE90S4,NS87RF57-YS63M4,NS87RF57-YS71M4,NS87RF57-YS80M4,NS87RF57-YS90S4,NS87RF57-YVB63M4,NS87RF57-YVB71M4,NS87RF57-YVB80M4,NS87RF57-YVB90S4,NS87RF57-YVP63M4,NS87RF57-YVP71M4,NS87RF57-YVP80M4,NS87RF57-YVP90S4,SW87RW57-Y63M4,SW87RW57-Y71M4,SW87RW57-Y80M4,SW87RW57-Y90M4,SW87RWF57-Y0.12KW,SW87RWF57-Y0.18KW,SW87RWF57-Y0.25KW,SW87RWF57-Y0.37KW,SW87RWF57-Y0.55KW,SW87RWF57-Y0.75KW,SW87RWF57-Y1.1KW,SW87RWF57-Y1.5KW,SW87RWF57-Y63M4,SW87RWF57-Y71M4,SW87RWF57-Y80M4,SW87RWF57-Y90M4,SW87RWF57-YB63M4,SW87RWF57-YB71M4,SW87RWF57-YB80M4,SW87RWF57-YB90S4,SW87RWF57-YDP63M4,SW87RWF57-YDP71M4,SW87RWF57-YDP80M4,SW87RWF57-YDP90S4,SW87RWF57-YE63M4,SW87RWF57-YE71M4,SW87RWF57-YE80M4,SW87RWF57-YE90S4,SW87RWF57-YEJ63M4,SW87RWF57-YEJ71M4,SW87RWF57-YEJ80M4,SW87RWF57-YEJ90S4,SW87RWF57-YEJB63M4,SW87RWF57-YEJB71M4,SW87RWF57-YEJB80M4,SW87RWF57-YEJB90S4,SW87RWF57-YP63M4,SW87RWF57-YP71M4,SW87RWF57-YP80M4,SW87RWF57-YP90S4,SW87RWF57-YPB63M4,SW87RWF57-YPB71M4,SW87RWF57-YPB80M4,SW87RWF57-YPB90S4,SW87RWF57-YPE63M4,SW87RWF57-YPE71M4,SW87RWF57-YPE80M4,SW87RWF57-YPE90S4,SW87RWF57-YS63M4,SW87RWF57-YS71M4,SW87RWF57-YS80M4,SW87RWF57-YS90S4,SW87RWF57-YVB63M4,SW87RWF57-YVB71M4,SW87RWF57-YVB80M4,SW87RWF57-YVB90S4,SW87RWF57-YVP63M4,SW87RWF57-YVP71M4,SW87RWF57-YVP80M4,SW87RWF57-YVP90S4,S89R59-Y63M4,S89R59-Y71M4,S89R59-Y80M4,S89R59-Y90M4,S89RF59-Y0.12KW,S89RF59-Y0.18KW,S89RF59-Y0.25KW,S89RF59-Y0.37KW,S89RF59-Y0.55KW,S89RF59-Y0.75KW,S89RF59-Y1.1KW,S89RF59-Y1.5KW,S89RF59-Y63M4,S89RF59-Y71M4,S89RF59-Y80M4,S89RF59-Y90M4,S89RF59-YB63M4,S89RF59-YB71M4,S89RF59-YB80M4,S89RF59-YB90S4,S89RF59-YDP63M4,S89RF59-YDP71M4,S89RF59-YDP80M4,S89RF59-YDP90S4,S89RF59-YE63M4,S89RF59-YE71M4,S89RF59-YE80M4,S89RF59-YE90S4,S89RF59-YEJ63M4,S89RF59-YEJ71M4,S89RF59-YEJ80M4,S89RF59-YEJ90S4,S89RF59-YEJB63M4,S89RF59-YEJB71M4,S89RF59-YEJB80M4,S89RF59-YEJB90S4,S89RF59-YP63M4,S89RF59-YP71M4,S89RF59-YP80M4,S89RF59-YP90S4,S89RF59-YPB63M4,S89RF59-YPB71M4,S89RF59-YPB80M4,S89RF59-YPB90S4,S89RF59-YPE63M4,S89RF59-YPE71M4,S89RF59-YPE80M4,S89RF59-YPE90S4,S89RF59-YS63M4,S89RF59-YS71M4,S89RF59-YS80M4,S89RF59-YS90S4,S89RF59-YVB63M4,S89RF59-YVB71M4,S89RF59-YVB80M4,S89RF59-YVB90S4,S89RF59-YVP63M4,S89RF59-YVP71M4,S89RF59-YVP80M4,S89RF59-YVP90S4。
S89R59減速電機生產廠家:看廠請聯系微信13827261050,獲取位置,需提前一天預約http://njxyx.com/product/list-sxiliejiansuji-cn.html
推薦型號:S89減速機
關鍵詞:減速機帶司服電機連接一體機_S系列減速機_G系列減速機_S型減速機_司服電機減速機_S系列斜齒輪蝸輪蝸桿減速機_S系列減速器_司服減速機
S系列減速機型號:S39減速機,S49減速機,S59減速機,S69減速機,S79減速機,S89減速機,S99齒輪減速電機
S系列自鎖減速機可配變頻電機,剎車電機,防爆電機,伺服電機,交流電機,直流電機,三相電機,單相電機 0.12KW-22KW之間
如需工程師幫選型,請加微信13827261050,留言告知工程師參數要求
