S79R39減速機銘牌參數說明解讀含義:有關型號描述的詳細情況及其他信息可以參閱本業附件下載中的S79R39減速機選型樣本。
S79R39-Y0.25KW-4P-637-M2-0°
S/R:系列代號
79/39:減速機規格代號
Y:電機
0.25KW:電機功率
4P:電機級數
637:減速機傳動比
M2:減速機安裝位置
0°:接線盒位置
S79R39減速機電機接線注意事項:
電機本體并不附帶保護裝置。按照電氣設備技術標準的規定,必須安裝過載保護裝置。同時,推薦安裝漏電斷路器等其它保護裝置。否則有可能會導致?lián)p傷、觸電、火災、燒傷。齒輪減速電機
請將接線時的電壓壓降控制在2%以內,接線距離過長,可導致電壓壓降過大,電機可能無法啟動。
進行反轉時,請務必先暫停,然后開始反轉。逆向制動引起的正反運轉可能會損壞裝置。
附帶制動器時,制動線圈應與電機繞組同步通斷。
測定絕緣電阻時,請勿觸摸端子。否則有可能會導致觸電。
若繞組通制動不通,電機會卡死燒機;若制動通繞組不通,有可能會導致線圈燒毀、火災。自鎖減速機
S79R39減速機電機噪音故障維修:
風葉擦風罩將,風葉/風罩扳正,或更換變型零部件;
軸承壞,更換軸承;
底板松動,擰緊固定螺栓;
電機缺相運行:電源接觸不良,修復觸點及電源線路;
電機缺相運行:線圈斷路,更換定子線圈;
氣隙不均,檢查并校正軸承座配合/更換端蓋或法蘭;
定轉子擦,更換電機;
轉子不平衡量大,重新校平衡;S系列減速機
轉子斷條,更換轉子;線圈內有一個線苞嵌反,更換定子線圈。
S79R39減速電機型號:
YQS77R37-Y63M4,YQS77R37-Y71M4,YQS77R37-Y80M4,YQS77R37-Y90M4,YQS77RF37-Y0.12KW,YQS77RF37-Y0.18KW,YQS77RF37-Y0.25KW,YQS77RF37-Y0.37KW,YQS77RF37-Y0.55KW,YQS77RF37-Y0.75KW,YQS77RF37-Y1.1KW,YQS77RF37-Y63M4,YQS77RF37-Y71M4,YQS77RF37-Y80M4,YQS77RF37-Y90M4,YQS77RF37-YB63M4,YQS77RF37-YB71M4,YQS77RF37-YB80M4,YQS77RF37-YB90S4,YQS77RF37-YDP63M4,YQS77RF37-YDP71M4,YQS77RF37-YDP80M4,YQS77RF37-YDP90S4,YQS77RF37-YE63M4,YQS77RF37-YE71M4,YQS77RF37-YE80M4,YQS77RF37-YE90S4,YQS77RF37-YEJ63M4,YQS77RF37-YEJ71M4,YQS77RF37-YEJ80M4,YQS77RF37-YEJ90S4,YQS77RF37-YEJB63M4,YQS77RF37-YEJB71M4,YQS77RF37-YEJB80M4,YQS77RF37-YEJB90S4,YQS77RF37-YP63M4,YQS77RF37-YP71M4,YQS77RF37-YP80M4,YQS77RF37-YP90S4,YQS77RF37-YPB63M4,YQS77RF37-YPB71M4,YQS77RF37-YPB80M4,YQS77RF37-YPB90S4,YQS77RF37-YPE63M4,YQS77RF37-YPE71M4,YQS77RF37-YPE80M4,YQS77RF37-YPE90S4,YQS77RF37-YS63M4,YQS77RF37-YS71M4,YQS77RF37-YS80M4,YQS77RF37-YS90S4,YQS77RF37-YVB63M4,YQS77RF37-YVB71M4,YQS77RF37-YVB80M4,YQS77RF37-YVB90S4,YQS77RF37-YVP63M4,YQS77RF37-YVP71M4,YQS77RF37-YVP80M4,YQS77RF37-YVP90S4,AS77R37-Y63M4,AS77R37-Y71M4,AS77R37-Y80M4,AS77R37-Y90M4,AS77RF37-Y0.12KW,AS77RF37-Y0.18KW,AS77RF37-Y0.25KW,AS77RF37-Y0.37KW,AS77RF37-Y0.55KW,AS77RF37-Y0.75KW,AS77RF37-Y1.1KW,AS77RF37-Y63M4,AS77RF37-Y71M4,AS77RF37-Y80M4,AS77RF37-Y90M4,AS77RF37-YB63M4,AS77RF37-YB71M4,AS77RF37-YB80M4,AS77RF37-YB90S4,AS77RF37-YDP63M4,AS77RF37-YDP71M4,AS77RF37-YDP80M4,AS77RF37-YDP90S4,AS77RF37-YE63M4,AS77RF37-YE71M4,AS77RF37-YE80M4,AS77RF37-YE90S4,AS77RF37-YEJ63M4,AS77RF37-YEJ71M4,AS77RF37-YEJ80M4,AS77RF37-YEJ90S4,AS77RF37-YEJB63M4,AS77RF37-YEJB71M4,AS77RF37-YEJB80M4,AS77RF37-YEJB90S4,AS77RF37-YP63M4,AS77RF37-YP71M4,AS77RF37-YP80M4,AS77RF37-YP90S4,AS77RF37-YPB63M4,AS77RF37-YPB71M4,AS77RF37-YPB80M4,AS77RF37-YPB90S4,AS77RF37-YPE63M4,AS77RF37-YPE71M4,AS77RF37-YPE80M4,AS77RF37-YPE90S4,AS77RF37-YS63M4,AS77RF37-YS71M4,AS77RF37-YS80M4,AS77RF37-YS90S4,AS77RF37-YVB63M4,AS77RF37-YVB71M4,AS77RF37-YVB80M4,AS77RF37-YVB90S4,AS77RF37-YVP63M4,AS77RF37-YVP71M4,AS77RF37-YVP80M4,AS77RF37-YVP90S4,SS77R37-Y63M4,SS77R37-Y71M4,SS77R37-Y80M4,SS77R37-Y90M4,SS77RF37-Y0.12KW,SS77RF37-Y0.18KW,SS77RF37-Y0.25KW,SS77RF37-Y0.37KW,SS77RF37-Y0.55KW,SS77RF37-Y0.75KW,SS77RF37-Y1.1KW,SS77RF37-Y63M4,SS77RF37-Y71M4,SS77RF37-Y80M4,SS77RF37-Y90M4,SS77RF37-YB63M4,SS77RF37-YB71M4,SS77RF37-YB80M4,SS77RF37-YB90S4,SS77RF37-YDP63M4,SS77RF37-YDP71M4,SS77RF37-YDP80M4,SS77RF37-YDP90S4,SS77RF37-YE63M4,SS77RF37-YE71M4,SS77RF37-YE80M4,SS77RF37-YE90S4,SS77RF37-YEJ63M4,SS77RF37-YEJ71M4,SS77RF37-YEJ80M4,SS77RF37-YEJ90S4,SS77RF37-YEJB63M4,SS77RF37-YEJB71M4,SS77RF37-YEJB80M4,SS77RF37-YEJB90S4,SS77RF37-YP63M4,SS77RF37-YP71M4,SS77RF37-YP80M4,SS77RF37-YP90S4,SS77RF37-YPB63M4,SS77RF37-YPB71M4,SS77RF37-YPB80M4,SS77RF37-YPB90S4,SS77RF37-YPE63M4,SS77RF37-YPE71M4,SS77RF37-YPE80M4,SS77RF37-YPE90S4,SS77RF37-YS63M4,SS77RF37-YS71M4,SS77RF37-YS80M4,SS77RF37-YS90S4,SS77RF37-YVB63M4,SS77RF37-YVB71M4,SS77RF37-YVB80M4,SS77RF37-YVB90S4,SS77RF37-YVP63M4,SS77RF37-YVP71M4,SS77RF37-YVP80M4,SS77RF37-YVP90S4,WS77R37-Y63M4,WS77R37-Y71M4,WS77R37-Y80M4,WS77R37-Y90M4,WS77RF37-Y0.12KW,WS77RF37-Y0.18KW,WS77RF37-Y0.25KW,WS77RF37-Y0.37KW,WS77RF37-Y0.55KW,WS77RF37-Y0.75KW,WS77RF37-Y1.1KW,WS77RF37-Y63M4,WS77RF37-Y71M4,WS77RF37-Y80M4,WS77RF37-Y90M4,WS77RF37-YB63M4,WS77RF37-YB71M4,WS77RF37-YB80M4,WS77RF37-YB90S4,WS77RF37-YDP63M4,WS77RF37-YDP71M4,WS77RF37-YDP80M4,WS77RF37-YDP90S4,WS77RF37-YE63M4,WS77RF37-YE71M4,WS77RF37-YE80M4,WS77RF37-YE90S4,WS77RF37-YEJ63M4,WS77RF37-YEJ71M4,WS77RF37-YEJ80M4,WS77RF37-YEJ90S4,WS77RF37-YEJB63M4,WS77RF37-YEJB71M4,WS77RF37-YEJB80M4,WS77RF37-YEJB90S4,WS77RF37-YP63M4,WS77RF37-YP71M4,WS77RF37-YP80M4,WS77RF37-YP90S4,WS77RF37-YPB63M4,WS77RF37-YPB71M4,WS77RF37-YPB80M4,WS77RF37-YPB90S4,WS77RF37-YPE63M4,WS77RF37-YPE71M4,WS77RF37-YPE80M4,WS77RF37-YPE90S4,WS77RF37-YS63M4,WS77RF37-YS71M4,WS77RF37-YS80M4,WS77RF37-YS90S4,WS77RF37-YVB63M4,WS77RF37-YVB71M4,WS77RF37-YVB80M4,WS77RF37-YVB90S4,WS77RF37-YVP63M4,WS77RF37-YVP71M4,WS77RF37-YVP80M4,WS77RF37-YVP90S4,XDS77R37-Y63M4,XDS77R37-Y71M4,XDS77R37-Y80M4,XDS77R37-Y90M4,XDS77RF37-Y0.12KW,XDS77RF37-Y0.18KW,XDS77RF37-Y0.25KW,XDS77RF37-Y0.37KW,XDS77RF37-Y0.55KW,XDS77RF37-Y0.75KW,XDS77RF37-Y1.1KW,XDS77RF37-Y63M4,XDS77RF37-Y71M4,XDS77RF37-Y80M4,XDS77RF37-Y90M4,XDS77RF37-YB63M4,XDS77RF37-YB71M4,XDS77RF37-YB80M4,XDS77RF37-YB90S4,XDS77RF37-YDP63M4,XDS77RF37-YDP71M4,XDS77RF37-YDP80M4,XDS77RF37-YDP90S4,XDS77RF37-YE63M4,XDS77RF37-YE71M4,XDS77RF37-YE80M4,XDS77RF37-YE90S4,XDS77RF37-YEJ63M4,XDS77RF37-YEJ71M4,XDS77RF37-YEJ80M4,XDS77RF37-YEJ90S4,XDS77RF37-YEJB63M4,XDS77RF37-YEJB71M4,XDS77RF37-YEJB80M4,XDS77RF37-YEJB90S4,XDS77RF37-YP63M4,XDS77RF37-YP71M4,XDS77RF37-YP80M4,XDS77RF37-YP90S4,XDS77RF37-YPB63M4,XDS77RF37-YPB71M4,XDS77RF37-YPB80M4,XDS77RF37-YPB90S4,XDS77RF37-YPE63M4,XDS77RF37-YPE71M4,XDS77RF37-YPE80M4,XDS77RF37-YPE90S4,XDS77RF37-YS63M4,XDS77RF37-YS71M4,XDS77RF37-YS80M4,XDS77RF37-YS90S4,XDS77RF37-YVB63M4,XDS77RF37-YVB71M4,XDS77RF37-YVB80M4,XDS77RF37-YVB90S4,XDS77RF37-YVP63M4,XDS77RF37-YVP71M4,XDS77RF37-YVP80M4,XDS77RF37-YVP90S4,JCS77R37-Y63M4,JCS77R37-Y71M4,JCS77R37-Y80M4,JCS77R37-Y90M4,JCS77RF37-Y0.12KW,JCS77RF37-Y0.18KW,JCS77RF37-Y0.25KW,JCS77RF37-Y0.37KW,JCS77RF37-Y0.55KW,JCS77RF37-Y0.75KW,JCS77RF37-Y1.1KW,JCS77RF37-Y63M4,JCS77RF37-Y71M4,JCS77RF37-Y80M4,JCS77RF37-Y90M4,JCS77RF37-YB63M4,JCS77RF37-YB71M4,JCS77RF37-YB80M4,JCS77RF37-YB90S4,JCS77RF37-YDP63M4,JCS77RF37-YDP71M4,JCS77RF37-YDP80M4,JCS77RF37-YDP90S4,JCS77RF37-YE63M4,JCS77RF37-YE71M4,JCS77RF37-YE80M4,JCS77RF37-YE90S4,JCS77RF37-YEJ63M4,JCS77RF37-YEJ71M4,JCS77RF37-YEJ80M4,JCS77RF37-YEJ90S4,JCS77RF37-YEJB63M4,JCS77RF37-YEJB71M4,JCS77RF37-YEJB80M4,JCS77RF37-YEJB90S4,JCS77RF37-YP63M4,JCS77RF37-YP71M4,JCS77RF37-YP80M4,JCS77RF37-YP90S4,JCS77RF37-YPB63M4,JCS77RF37-YPB71M4,JCS77RF37-YPB80M4,JCS77RF37-YPB90S4,JCS77RF37-YPE63M4,JCS77RF37-YPE71M4,JCS77RF37-YPE80M4,JCS77RF37-YPE90S4,JCS77RF37-YS63M4,JCS77RF37-YS71M4,JCS77RF37-YS80M4,JCS77RF37-YS90S4,JCS77RF37-YVB63M4,JCS77RF37-YVB71M4,JCS77RF37-YVB80M4,JCS77RF37-YVB90S4,JCS77RF37-YVP63M4,JCS77RF37-YVP71M4,JCS77RF37-YVP80M4,JCS77RF37-YVP90S4,NS77R37-Y63M4,NS77R37-Y71M4,NS77R37-Y80M4,NS77R37-Y90M4,NS77RF37-Y0.12KW,NS77RF37-Y0.18KW,NS77RF37-Y0.25KW,NS77RF37-Y0.37KW,NS77RF37-Y0.55KW,NS77RF37-Y0.75KW,NS77RF37-Y1.1KW,NS77RF37-Y63M4,NS77RF37-Y71M4,NS77RF37-Y80M4,NS77RF37-Y90M4,NS77RF37-YB63M4,NS77RF37-YB71M4,NS77RF37-YB80M4,NS77RF37-YB90S4,NS77RF37-YDP63M4,NS77RF37-YDP71M4,NS77RF37-YDP80M4,NS77RF37-YDP90S4,NS77RF37-YE63M4,NS77RF37-YE71M4,NS77RF37-YE80M4,NS77RF37-YE90S4,NS77RF37-YEJ63M4,NS77RF37-YEJ71M4,NS77RF37-YEJ80M4,NS77RF37-YEJ90S4,NS77RF37-YEJB63M4,NS77RF37-YEJB71M4,NS77RF37-YEJB80M4,NS77RF37-YEJB90S4,NS77RF37-YP63M4,NS77RF37-YP71M4,NS77RF37-YP80M4,NS77RF37-YP90S4,NS77RF37-YPB63M4,NS77RF37-YPB71M4,NS77RF37-YPB80M4,NS77RF37-YPB90S4,NS77RF37-YPE63M4,NS77RF37-YPE71M4,NS77RF37-YPE80M4,NS77RF37-YPE90S4,NS77RF37-YS63M4,NS77RF37-YS71M4,NS77RF37-YS80M4,NS77RF37-YS90S4,NS77RF37-YVB63M4,NS77RF37-YVB71M4,NS77RF37-YVB80M4,NS77RF37-YVB90S4,NS77RF37-YVP63M4,NS77RF37-YVP71M4,NS77RF37-YVP80M4,NS77RF37-YVP90S4,SW77RW37-Y63M4,SW77RW37-Y71M4,SW77RW37-Y80M4,SW77RW37-Y90M4,SW77RWF37-Y0.12KW,SW77RWF37-Y0.18KW,SW77RWF37-Y0.25KW,SW77RWF37-Y0.37KW,SW77RWF37-Y0.55KW,SW77RWF37-Y0.75KW,SW77RWF37-Y1.1KW,SW77RWF37-Y63M4,SW77RWF37-Y71M4,SW77RWF37-Y80M4,SW77RWF37-Y90M4,SW77RWF37-YB63M4,SW77RWF37-YB71M4,SW77RWF37-YB80M4,SW77RWF37-YB90S4,SW77RWF37-YDP63M4,SW77RWF37-YDP71M4,SW77RWF37-YDP80M4,SW77RWF37-YDP90S4,SW77RWF37-YE63M4,SW77RWF37-YE71M4,SW77RWF37-YE80M4,SW77RWF37-YE90S4,SW77RWF37-YEJ63M4,SW77RWF37-YEJ71M4,SW77RWF37-YEJ80M4,SW77RWF37-YEJ90S4,SW77RWF37-YEJB63M4,SW77RWF37-YEJB71M4,SW77RWF37-YEJB80M4,SW77RWF37-YEJB90S4,SW77RWF37-YP63M4,SW77RWF37-YP71M4,SW77RWF37-YP80M4,SW77RWF37-YP90S4,SW77RWF37-YPB63M4,SW77RWF37-YPB71M4,SW77RWF37-YPB80M4,SW77RWF37-YPB90S4,SW77RWF37-YPE63M4,SW77RWF37-YPE71M4,SW77RWF37-YPE80M4,SW77RWF37-YPE90S4,SW77RWF37-YS63M4,SW77RWF37-YS71M4,SW77RWF37-YS80M4,SW77RWF37-YS90S4,SW77RWF37-YVB63M4,SW77RWF37-YVB71M4,SW77RWF37-YVB80M4,SW77RWF37-YVB90S4,SW77RWF37-YVP63M4,SW77RWF37-YVP71M4,SW77RWF37-YVP80M4,SW77RWF37-YVP90S4,S79R39-Y63M4,S79R39-Y71M4,S79R39-Y80M4,S79R39-Y90M4,S79RF39-Y0.12KW,S79RF39-Y0.18KW,S79RF39-Y0.25KW,S79RF39-Y0.39KW,S79RF39-Y0.55KW,S79RF39-Y0.75KW,S79RF39-Y1.1KW,S79RF39-Y63M4,S79RF39-Y71M4,S79RF39-Y80M4,S79RF39-Y90M4,S79RF39-YB63M4,S79RF39-YB71M4,S79RF39-YB80M4,S79RF39-YB90S4,S79RF39-YDP63M4,S79RF39-YDP71M4,S79RF39-YDP80M4,S79RF39-YDP90S4,S79RF39-YE63M4,S79RF39-YE71M4,S79RF39-YE80M4,S79RF39-YE90S4,S79RF39-YEJ63M4,S79RF39-YEJ71M4,S79RF39-YEJ80M4,S79RF39-YEJ90S4,S79RF39-YEJB63M4,S79RF39-YEJB71M4,S79RF39-YEJB80M4,S79RF39-YEJB90S4,S79RF39-YP63M4,S79RF39-YP71M4,S79RF39-YP80M4,S79RF39-YP90S4,S79RF39-YPB63M4,S79RF39-YPB71M4,S79RF39-YPB80M4,S79RF39-YPB90S4,S79RF39-YPE63M4,S79RF39-YPE71M4,S79RF39-YPE80M4,S79RF39-YPE90S4,S79RF39-YS63M4,S79RF39-YS71M4,S79RF39-YS80M4,S79RF39-YS90S4,S79RF39-YVB63M4,S79RF39-YVB71M4,S79RF39-YVB80M4,S79RF39-YVB90S4,S79RF39-YVP63M4,S79RF39-YVP71M4,S79RF39-YVP80M4,S79RF39-YVP90S4。
S79R39減速電機生產廠家:看廠請聯系微信13827261050,獲取位置,需提前一天預約http://njxyx.com/product/list-sxiliejiansuji-cn.html
推薦型號:S79減速機
關鍵詞:減速機帶司服電機連接一體機_S系列減速機_G系列減速機_S型減速機_司服電機減速機_S系列斜齒輪蝸輪蝸桿減速機_S系列減速器_司服減速機
S系列減速機型號:S39減速機,S49減速機,S59減速機,S69減速機,S79減速機,S89減速機,S99齒輪減速電機
S系列自鎖減速機可配變頻電機,剎車電機,防爆電機,伺服電機,交流電機,直流電機,三相電機,單相電機 0.12KW-22KW之間
如需工程師幫選型,請加微信13827261050,留言告知工程師參數要求
