RF49減速機銘牌參數說明解讀含義:有關型號描述的詳細情況及其他信息可以參閱本業附件下載中的RF49減速機選型樣本。
RF49-BVP112M4-3.83-M2-90°
RF:系列代號
49:減速機規格代號
B:電機
VP:變頻電機
112:電機規格代號
M:電機定子鐵心長度代號
4:電機級數
3.83:減速機傳動比
M2:減速機安裝位置
90°:接線盒位置
RF49減速機潤滑油型號:
RF49減速機特殊應用場合必須使用特殊潤滑油,比如要求長使用壽命潤滑油。若需要可提供用于食品行業和生物降解潤滑油。
RF49減速機潤滑油加注量,具體值根據級數與傳動比的不同而各異。請您在加注潤滑油時一定注意油位螺栓所指示的精確油量。本頁附件中的RF49減速機選型樣本中列出了安裝位置從M1到M6RF49減速機相應的潤滑油加注標準,請自行下載查看。
RF49減速機某些安裝位置發生攪油損失的機會較高。出現下列情況時請與BOSERL公司進行聯系:若無特殊規定,BOSERL公司發貨時會根據RF49減速機的安裝位置給驅動裝置加潤滑油,因此應在訂貨時指定安裝位置(M1…M6,參見“RF49減速機說明書中的安裝位置與訂貨說明”章節)。若之后對安裝位置需要改動,則加潤滑油必須與安裝位置相符(潤滑油加注量)。RF系列減速機
RF49減速機推薦使用的潤滑油,其等級和粘度指標見下表:
ISO標準潤滑油 | 粘貼指標 | 環境溫度°C | 減速機型號 |
MINERALOILCLP(cc) | ISOVG220 | -10-+40 | R系列、F系列、K系列減速機 |
ISOVG680 | 0-+40 | S系列減速機 |
ISO標準潤滑油 | 粘貼指標 | 環境溫度°C | 減速機型號 |
MINERALOILCLP(cc) | ISOVG100 | -20-+25 | R系列、F系列、K系列減速機 |
Synthetic fluid,clp pg | ISOVG220 | -25-+80 | R系列、F系列、K系列減速機 |
Synthetic fluid,CLP HC | ISOVG460 | -30-+80 | S系列減速機 |
RF49減速機使用說明:
RF49減速機的螺母:立式安裝RF49減速機輸出法蘭直徑140螺母規格M8;立式安裝RF49減速機輸出法蘭直徑200螺母規格M10;RF49減速機螺母/螺母擰緊扭矩強度等級10.9。齒輪減速電機
RF49減速機危險使用說明:驅動裝置意外啟動會造成擠傷,可能造成重傷或死亡;開始工作前,應先斷開減速電機的電源并且采取措施防止意外接通!
RF49減速機警告說明:由于RF49減速機發熱或RF49減速機油溫過高可能引起燙傷;對RF49減速機進行操作前先冷卻;擰出油位檢查螺栓和放油螺栓時要格外小心。
RF49減速機注意事項:若未注入正確的RF49減速機油則可能造成潤滑油性能失效,可能造成財產損失;合成潤滑油不可能相互混用并不可與礦物潤滑油混用;礦物油用作標準的潤滑油,不能用于特殊行業。
RF49減速機提示事項:油位檢查螺栓、放油螺栓、以及透氣閥的位置在安裝位置上,要參見RF49減速機說明書安裝位置章節中的內容。立式減速機
RF49減速機型號:
YQRF47-AM100M4,YQRF47-AM112M4,YQRF47-AM132M4,YQRF47-AM63M4,YQRF47-AM71M4,YQRF47-AM80M4,YQRF47-AM90M4,YQRF47-Y0.12KW,YQRF47-Y0.18KW,YQRF47-Y0.25KW,YQRF47-Y0.37KW,YQRF47-Y0.55KW,YQRF47-Y0.75KW,YQRF47-Y1.1KW,YQRF47-Y1.5KW,YQRF47-Y100M4,YQRF47-Y112M4,YQRF47-Y132M4,YQRF47-Y2.2KW,YQRF47-Y3KW,YQRF47-Y4KW,YQRF47-Y5.5KW,YQRF47-Y63M4,YQRF47-Y7.5KW,YQRF47-Y71M4,YQRF47-Y80M4,YQRF47-Y90M4,YQRF47-YB100M4,YQRF47-YB112M4,YQRF47-YB132M4,YQRF47-YB63M4,YQRF47-YB71M4,YQRF47-YB80M4,YQRF47-YB90M4,YQRF47-YDP100M4,YQRF47-YDP112M4,YQRF47-YDP132M4,YQRF47-YDP63M4,YQRF47-YDP71M4,YQRF47-YDP80M4,YQRF47-YDP90M4,YQRF47-YE100M4,YQRF47-YE112M4,YQRF47-YE132M4,YQRF47-YE63M4,YQRF47-YE71M4,YQRF47-YE80M4,YQRF47-YE90M4,YQRF47-YEJ100M4,YQRF47-YEJ112M4,YQRF47-YEJ132M4,YQRF47-YEJ63M4,YQRF47-YEJ71M4,YQRF47-YEJ80M4,YQRF47-YEJ90M4,YQRF47-YEJB100M4,YQRF47-YEJB112M4,YQRF47-YEJB132M4,YQRF47-YEJB63M4,YQRF47-YEJB71M4,YQRF47-YEJB80M4,YQRF47-YEJB90M4,YQRF47-YP100M4,YQRF47-YP112M4,YQRF47-YP132M4,YQRF47-YP63M4,YQRF47-YP71M4,YQRF47-YP80M4,YQRF47-YP90M4,YQRF47-YPB100M4,YQRF47-YPB112M4,YQRF47-YPB132M4,YQRF47-YPB63M4,YQRF47-YPB71M4,YQRF47-YPB80M4,YQRF47-YPB90M4,YQRF47-YPE100M4,YQRF47-YPE112M4,YQRF47-YPE132M4,YQRF47-YPE63M4,YQRF47-YPE71M4,YQRF47-YPE80M4,YQRF47-YPE90M4,YQRF47-YS100M4,YQRF47-YS112M4,YQRF47-YS132M4,YQRF47-YS63M4,YQRF47-YS71M4,YQRF47-YS80M4,YQRF47-YS90M4,YQRF47-YVB100M4,YQRF47-YVB112M4,YQRF47-YVB132M4,YQRF47-YVB63M4,YQRF47-YVB71M4,YQRF47-YVB80M4,YQRF47-YVB90M4,YQRF47-YVP100M4,YQRF47-YVP112M4,YQRF47-YVP132M4,YQRF47-YVP63M4,YQRF47-YVP71M4,YQRF47-YVP80M4,YQRF47-YVP90M4,YQRF47-YVPEJ100M4,YQRF47-YVPEJ112M4,YQRF47-YVPEJ132M4,YQRF47-YVPEJ63M4,YQRF47-YVPEJ71M4,YQRF47-YVPEJ80M4,YQRF47-YVPEJ90M4,JCRF47-AM100M4,JCRF47-AM112M4,JCRF47-AM132M4,JCRF47-AM63M4,JCRF47-AM71M4,JCRF47-AM80M4,JCRF47-AM90M4,JCRF47-Y0.12KW,JCRF47-Y0.18KW,JCRF47-Y0.25KW,JCRF47-Y0.37KW,JCRF47-Y0.55KW,JCRF47-Y0.75KW,JCRF47-Y1.1KW,JCRF47-Y1.5KW,JCRF47-Y100M4,JCRF47-Y112M4,JCRF47-Y132M4,JCRF47-Y2.2KW,JCRF47-Y3KW,JCRF47-Y4KW,JCRF47-Y5.5KW,JCRF47-Y63M4,JCRF47-Y7.5KW,JCRF47-Y71M4,JCRF47-Y80M4,JCRF47-Y90M4,JCRF47-YB100M4,JCRF47-YB112M4,JCRF47-YB132M4,JCRF47-YB63M4,JCRF47-YB71M4,JCRF47-YB80M4,JCRF47-YB90M4,JCRF47-YDP100M4,JCRF47-YDP112M4,JCRF47-YDP132M4,JCRF47-YDP63M4,JCRF47-YDP71M4,JCRF47-YDP80M4,JCRF47-YDP90M4,JCRF47-YE100M4,JCRF47-YE112M4,JCRF47-YE132M4,JCRF47-YE63M4,JCRF47-YE71M4,JCRF47-YE80M4,JCRF47-YE90M4,JCRF47-YEJ100M4,JCRF47-YEJ112M4,JCRF47-YEJ132M4,JCRF47-YEJ63M4,JCRF47-YEJ71M4,JCRF47-YEJ80M4,JCRF47-YEJ90M4,JCRF47-YEJB100M4,JCRF47-YEJB112M4,JCRF47-YEJB132M4,JCRF47-YEJB63M4,JCRF47-YEJB71M4,JCRF47-YEJB80M4,JCRF47-YEJB90M4,JCRF47-YP100M4,JCRF47-YP112M4,JCRF47-YP132M4,JCRF47-YP63M4,JCRF47-YP71M4,JCRF47-YP80M4,JCRF47-YP90M4,JCRF47-YPB100M4,JCRF47-YPB112M4,JCRF47-YPB132M4,JCRF47-YPB63M4,JCRF47-YPB71M4,JCRF47-YPB80M4,JCRF47-YPB90M4,JCRF47-YPE100M4,JCRF47-YPE112M4,JCRF47-YPE132M4,JCRF47-YPE63M4,JCRF47-YPE71M4,JCRF47-YPE80M4,JCRF47-YPE90M4,JCRF47-YS100M4,JCRF47-YS112M4,JCRF47-YS132M4,JCRF47-YS63M4,JCRF47-YS71M4,JCRF47-YS80M4,JCRF47-YS90M4,JCRF47-YVB100M4,JCRF47-YVB112M4,JCRF47-YVB132M4,JCRF47-YVB63M4,JCRF47-YVB71M4,JCRF47-YVB80M4,JCRF47-YVB90M4,JCRF47-YVP100M4,JCRF47-YVP112M4,JCRF47-YVP132M4,JCRF47-YVP63M4,JCRF47-YVP71M4,JCRF47-YVP80M4,JCRF47-YVP90M4,JCRF47-YVPEJ100M4,JCRF47-YVPEJ112M4,JCRF47-YVPEJ132M4,JCRF47-YVPEJ63M4,JCRF47-YVPEJ71M4,JCRF47-YVPEJ80M4,JCRF47-YVPEJ90M4,XDRF47-AM100M4,XDRF47-AM112M4,XDRF47-AM132M4,XDRF47-AM63M4,XDRF47-AM71M4,XDRF47-AM80M4,XDRF47-AM90M4,XDRF47-Y0.12KW,XDRF47-Y0.18KW,XDRF47-Y0.25KW,XDRF47-Y0.37KW,XDRF47-Y0.55KW,XDRF47-Y0.75KW,XDRF47-Y1.1KW,XDRF47-Y1.5KW,XDRF47-Y100M4,XDRF47-Y112M4,XDRF47-Y132M4,XDRF47-Y2.2KW,XDRF47-Y3KW,XDRF47-Y4KW,XDRF47-Y5.5KW,XDRF47-Y63M4,XDRF47-Y7.5KW,XDRF47-Y71M4,XDRF47-Y80M4,XDRF47-Y90M4,XDRF47-YB100M4,XDRF47-YB112M4,XDRF47-YB132M4,XDRF47-YB63M4,XDRF47-YB71M4,XDRF47-YB80M4,XDRF47-YB90M4,XDRF47-YDP100M4,XDRF47-YDP112M4,XDRF47-YDP132M4,XDRF47-YDP63M4,XDRF47-YDP71M4,XDRF47-YDP80M4,XDRF47-YDP90M4,XDRF47-YE100M4,XDRF47-YE112M4,XDRF47-YE132M4,XDRF47-YE63M4,XDRF47-YE71M4,XDRF47-YE80M4,XDRF47-YE90M4,XDRF47-YEJ100M4,XDRF47-YEJ112M4,XDRF47-YEJ132M4,XDRF47-YEJ63M4,XDRF47-YEJ71M4,XDRF47-YEJ80M4,XDRF47-YEJ90M4,XDRF47-YEJB100M4,XDRF47-YEJB112M4,XDRF47-YEJB132M4,XDRF47-YEJB63M4,XDRF47-YEJB71M4,XDRF47-YEJB80M4,XDRF47-YEJB90M4,XDRF47-YP100M4,XDRF47-YP112M4,XDRF47-YP132M4,XDRF47-YP63M4,XDRF47-YP71M4,XDRF47-YP80M4,XDRF47-YP90M4,XDRF47-YPB100M4,XDRF47-YPB112M4,XDRF47-YPB132M4,XDRF47-YPB63M4,XDRF47-YPB71M4,XDRF47-YPB80M4,XDRF47-YPB90M4,XDRF47-YPE100M4,XDRF47-YPE112M4,XDRF47-YPE132M4,XDRF47-YPE63M4,XDRF47-YPE71M4,XDRF47-YPE80M4,XDRF47-YPE90M4,XDRF47-YS100M4,XDRF47-YS112M4,XDRF47-YS132M4,XDRF47-YS63M4,XDRF47-YS71M4,XDRF47-YS80M4,XDRF47-YS90M4,XDRF47-YVB100M4,XDRF47-YVB112M4,XDRF47-YVB132M4,XDRF47-YVB63M4,XDRF47-YVB71M4,XDRF47-YVB80M4,XDRF47-YVB90M4,XDRF47-YVP100M4,XDRF47-YVP112M4,XDRF47-YVP132M4,XDRF47-YVP63M4,XDRF47-YVP71M4,XDRF47-YVP80M4,XDRF47-YVP90M4,XDRF47-YVPEJ100M4,XDRF47-YVPEJ112M4,XDRF47-YVPEJ132M4,XDRF47-YVPEJ63M4,XDRF47-YVPEJ71M4,XDRF47-YVPEJ80M4,XDRF47-YVPEJ90M4,RF49-AM100M4,RF49-AM112M4,RF49-AM132M4,RF49-AM63M4,RF49-AM71M4,RF49-AM80M4,RF49-AM90M4,RF49-Y0.12KW,RF49-Y0.18KW,RF49-Y0.25KW,RF49-Y0.37KW,RF49-Y0.55KW,RF49-Y0.75KW,RF49-Y1.1KW,RF49-Y1.5KW,RF49-Y100M4,RF49-Y112M4,RF49-Y132M4,RF49-Y2.2KW,RF49-Y3KW,RF49-Y4KW,RF49-Y5.5KW,RF49-Y63M4,RF49-Y7.5KW,RF49-Y71M4,RF49-Y80M4,RF49-Y90M4,RF49-YB100M4,RF49-YB112M4,RF49-YB132M4,RF49-YB63M4,RF49-YB71M4,RF49-YB80M4,RF49-YB90M4,RF49-YDP100M4,RF49-YDP112M4,RF49-YDP132M4,RF49-YDP63M4,RF49-YDP71M4,RF49-YDP80M4,RF49-YDP90M4,RF49-YE100M4,RF49-YE112M4,RF49-YE132M4,RF49-YE63M4,RF49-YE71M4,RF49-YE80M4,RF49-YE90M4,RF49-YEJ100M4,RF49-YEJ112M4,RF49-YEJ132M4,RF49-YEJ63M4,RF49-YEJ71M4,RF49-YEJ80M4,RF49-YEJ90M4,RF49-YEJB100M4,RF49-YEJB112M4,RF49-YEJB132M4,RF49-YEJB63M4,RF49-YEJB71M4,RF49-YEJB80M4,RF49-YEJB90M4,RF49-YP100M4,RF49-YP112M4,RF49-YP132M4,RF49-YP63M4,RF49-YP71M4,RF49-YP80M4,RF49-YP90M4,RF49-YPB100M4,RF49-YPB112M4,RF49-YPB132M4,RF49-YPB63M4,RF49-YPB71M4,RF49-YPB80M4,RF49-YPB90M4,RF49-YPE100M4,RF49-YPE112M4,RF49-YPE132M4,RF49-YPE63M4,RF49-YPE71M4,RF49-YPE80M4,RF49-YPE90M4,RF49-YS100M4,RF49-YS112M4,RF49-YS132M4,RF49-YS63M4,RF49-YS71M4,RF49-YS80M4,RF49-YS90M4,RF49-YVB100M4,RF49-YVB112M4,RF49-YVB132M4,RF49-YVB63M4,RF49-YVB71M4,RF49-YVB80M4,RF49-YVB90M4,RF49-YVP100M4,RF49-YVP112M4,RF49-YVP132M4,RF49-YVP63M4,RF49-YVP71M4,RF49-YVP80M4,RF49-YVP90M4,RF49-YVPEJ100M4,RF49-YVPEJ112M4,RF49-YVPEJ132M4,RF49-YVPEJ63M4,RF49-YVPEJ71M4,RF49-YVPEJ80M4,RF49-YVPEJ90M4,RWF47-AM100M4,RWF47-AM112M4,RWF47-AM132M4,RWF47-AM63M4,RWF47-AM71M4,RWF47-AM80M4,RWF47-AM90M4,RWF47-Y0.12KW,RWF47-Y0.18KW,RWF47-Y0.25KW,RWF47-Y0.37KW,RWF47-Y0.55KW,RWF47-Y0.75KW,RWF47-Y1.1KW,RWF47-Y1.5KW,RWF47-Y100M4,RWF47-Y112M4,RWF47-Y132M4,RWF47-Y2.2KW,RWF47-Y3KW,RWF47-Y4KW,RWF47-Y5.5KW,RWF47-Y63M4,RWF47-Y7.5KW,RWF47-Y71M4,RWF47-Y80M4,RWF47-Y90M4,RWF47-YB100M4,RWF47-YB112M4,RWF47-YB132M4,RWF47-YB63M4,RWF47-YB71M4,RWF47-YB80M4,RWF47-YB90M4,RWF47-YDP100M4,RWF47-YDP112M4,RWF47-YDP132M4,RWF47-YDP63M4,RWF47-YDP71M4,RWF47-YDP80M4,RWF47-YDP90M4,RWF47-YE100M4,RWF47-YE112M4,RWF47-YE132M4,RWF47-YE63M4,RWF47-YE71M4,RWF47-YE80M4,RWF47-YE90M4,RWF47-YEJ100M4,RWF47-YEJ112M4,RWF47-YEJ132M4,RWF47-YEJ63M4,RWF47-YEJ71M4,RWF47-YEJ80M4,RWF47-YEJ90M4,RWF47-YEJB100M4,RWF47-YEJB112M4,RWF47-YEJB132M4,RWF47-YEJB63M4,RWF47-YEJB71M4,RWF47-YEJB80M4,RWF47-YEJB90M4,RWF47-YP100M4,RWF47-YP112M4,RWF47-YP132M4,RWF47-YP63M4,RWF47-YP71M4,RWF47-YP80M4,RWF47-YP90M4,RWF47-YPB100M4,RWF47-YPB112M4,RWF47-YPB132M4,RWF47-YPB63M4,RWF47-YPB71M4,RWF47-YPB80M4,RWF47-YPB90M4,RWF47-YPE100M4,RWF47-YPE112M4,RWF47-YPE132M4,RWF47-YPE63M4,RWF47-YPE71M4,RWF47-YPE80M4,RWF47-YPE90M4,RWF47-YS100M4,RWF47-YS112M4,RWF47-YS132M4,RWF47-YS63M4,RWF47-YS71M4,RWF47-YS80M4,RWF47-YS90M4,RWF47-YVB100M4,RWF47-YVB112M4,RWF47-YVB132M4,RWF47-YVB63M4,RWF47-YVB71M4,RWF47-YVB80M4,RWF47-YVB90M4,RWF47-YVP100M4,RWF47-YVP112M4,RWF47-YVP132M4,RWF47-YVP63M4,RWF47-YVP71M4,RWF47-YVP80M4,RWF47-YVP90M4,RWF47-YVPEJ100M4,RWF47-YVPEJ112M4,RWF47-YVPEJ132M4,RWF47-YVPEJ63M4,RWF47-YVPEJ71M4,RWF47-YVPEJ80M4,RWF47-YVPEJ90M4。
RF49減速機生產廠家展示:看廠請聯系微信13827261050,獲取位置,需提前一天預約http://njxyx.com/product/list-rfxiliejiansuji-cn.html
